Teltonika FMB900 First Start-Up Quick Start Manual

Teltonika FMB900 First Start-Up Quick Start Manual

Small and smart tracker with bluetooth
Hide thumbs Also See for FMB900:
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
https://wiki.teltonika-gps.com/view/FMB900_First_Start
FMB900 First Start
Main Page
>
Basic Trackers
Small and smart tracker with Bluetooth
Contents
1 How to insert Micro-SIM card
How to insert Micro-SIM card
1.
Gently remove FMB900 cover using plastic pry tool from both sides.
2.
Insert Micro-SIM card as shown with PIN request disabled or read
enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing
forward to slot.
Attach device cover back.
3.
4.
Device is ready to be connected.
Micro-SIM card insertion/removal must be performed when device is powered off -
external voltage disconnected. Otherwise Micro-SIM card might be damaged or device
will not detect it.
>
FMB900
> FMB900 First Start
Security info
how to

Advertisement

loading

Related Manuals for Teltonika FMB900

Summary of Contents for Teltonika FMB900

  • Page 1: Table Of Contents

    5 Installation photos 6 Safety information 6.1 Precautions How to insert Micro-SIM card Gently remove FMB900 cover using plastic pry tool from both sides. Insert Micro-SIM card as shown with PIN request disabled or read Security info how to enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing forward to slot.

  • Page 2: Pinout

    Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. Configuration (Windows) At first FMB900 device will have default factory settings set. These settings should be changed according to the user's needs. Main configuration can be performed via Teltonika Configurator software.

  • Page 3: Quick Sms Configuration

    Maintenance and etc. FMB900 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...

  • Page 4: Quick Start Guide

    If device has made a record it is sent to the server every 120 seconds After successful SMS configuration, FMB900 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.

  • Page 5: Mounting Recommendations

    These points in the car are the battery terminals. Therefore, we recommend connecting the power of FMB900 (GND and POWER wires) directly to the battery terminals. Another valid option is to connect the wires to the main POWER cable inside the fuse box (if there is none, then to the power supply where the fuses of vehicle’s computer are), GND wire must be connected in a special point, designed to...

  • Page 6: Installation Photos

    Installation photos FMB900 is the device that has internal GNSS and GSM antenna. Device should be mounted with the sticker / engraving view to the open sky (metal free). FMB900 area with engraving is shown in figure below: FMB900 can be mounted under the plastic panel behind the front window, with the sticker / engraving direction to a window (sky).
