Power Switching
Feed Wiring (Section A)
Feed Wiring for MLO (left) and MCB (right) Applications
Refer to the following table for information on wiring the feed to the panel.
Feed Wire Information
TERMINAL CONNECTOR MAX
WIRE RANGE
Neutral and 10-2/0 AWG (CU) or
Main Lugs 6-2/0 AWG (AL)
6 - 300 kcmil (CU or AL)
Neutral Bus 14-10 AWG(CU) or
12-10 AWG (AL)
8 AWG (CU or AL)
6-4 AWG (CU or AL)
WARNING: Failure to properly tighten lugs may result in poor electrical connection and overheating of the terminals.
6 • CRESTRON GREEN LIGHT Power Switching
120 Volt Models
TORQUE
Current
15 lb-ft
(20.3 Nm)
21 lb-ft
(28.5 Nm)
20 lb-in
Amps
(2.3 Nm)
25 lb-in
(2.8 Nm)
35 lb-in
(4.0 Nm)
Use copper or aluminum conductors only – rated 75°C.
CRESTRON GREEN LIGHT™
Max CONNECTOR MAX
WIRE RANGE
6-350 kcmil (CU or AL)
1/0-750 kcmil (CU or AL)
225
14-6 AWG (CU or AL)
14-2/0 AWG (CU or AL)
277 Volt Models
TORQUE
Current
275-300 lb-in
(31.1-33.9 Nm)
24-35 lb-in
(2.7-4.0 Nm)
40-50 lb-in
(4.5-5.6 Nm)
Installation Guide – DOC. 6672B
