Teltonika FMB240 First Start-Up Quick Start Manual

Teltonika FMB240 First Start-Up Quick Start Manual

Gnss/gsm/bluetooth tracker with integrated can chip, internal gnss/gsm antennas and internal battery
Hide thumbs Also See for FMB240:
1
2
3
4
5
6
7
Table of Contents

Advertisement

Quick Links

Download this manual
https://wiki.teltonika-gps.com/view/FMB240_First_Start
FMB240 First Start
Main Page
>
CAN Trackers & Adapters
GNSS/GSM/Bluetooth tracker with integrated CAN chip, internal GNSS/GSM antennas and
internal battery
Contents
>
FMB240
> FMB240 First Start

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMB240 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Teltonika FMB240

Summary of Contents for Teltonika FMB240

  • Page 1 Main Page > CAN Trackers & Adapters > FMB240 > FMB240 First Start GNSS/GSM/Bluetooth tracker with integrated CAN chip, internal GNSS/GSM antennas and internal battery Contents 1 How to insert Micro-SIM card and connect battery 2 Battery placement after complete device disassembling 3 2x6 socket pinout 3.1 PC Connection (Windows)
  • Page 2 3.Insert SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Teltonika Configurator. Make sure that SIM card cut-off corner is pointing outward from slot. SIM slot 1 is closer to PCB, SIM slot 2 is the top one.
  • Page 3 CAN2H CAN2 High CAN1H CAN1 High PC Connection (Windows) Power-up FMB240 with DC voltage 10-30 V power supply using supplied power cable. LED’s should start blinking, see “FMB240 LED status”. Connect device to computer using Micro-USB cable or Bluetooth connection:...
  • Page 4 Various and etc. FMB240 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...
  • Page 5 If device has made a record it is sent to the server every 120 seconds After successful SMS configuration, FMB240 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika...
  • Page 6 These points in the car are the battery terminals. Therefore, we recommend connecting the power of FMB240 (GND and POWER wires) directly to the battery terminals. Another valid option is to connect the wires to the main POWER cable inside the fuse box (if there is none, then to the power supply where the fuses of vehicle’s computer are), GND wire must be connected in a special point, designed to connect GND vehicle computer.
  • Page 7 Device should be mounted with the sticker view to the open sky. FMB240 device should be mounted with the device logo view to the open sky for the best device performance with not less than ¾ of metal free area. FMB240 has IP67 protection class. Top performance is reached if mounted outside of the vehicle.
