Pinout Table 1 FMB209 pinout PIN NAME DESCRIPTION VCC (10-30) V Power supply DC (+). GND (-) Ground DC (-). DIN 1 Digital input, channel 1. DIN 2 Digital input, channel 2. Digital output, channel 1. Open collector output. DOUT 1 Max.
5. After configuration, see “PC Connection (Windows)”, attach device cover back and screw in all screws. Figure 6 Micro-SIM card insert Figure 7 Battery connection 6. Device is ready to be mounted. Figure 9 Device is ready Figure 8 Attaching cover back FMB209 | Wiki...
Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. 1. Power-up FMB209 with DC voltage (10 – 30 V) power supply using power cable. LED’s should start blinking, see “ Configuration (Windows) 2.
Page 8
– where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMB209 configuration using Configurator can be found in our Wiki. Figure 12 Configurator Status window FMB209 | Wiki...
2005 – Port • 2006 – Data sending protocol • After successful SMS configuration, FMB209 device will (0 – TCP, 1 – UDP) synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
GND will be ▬ It is recommended to connect to the main power cable in unpredictable, which can lead to unstable FMB209 the fuse box. ▬ 3 A, 125 V external fuse shall be used.
Device is not working or Device is in CELLULAR boot mode Technology 2G bands Quad-band 850 / 900 / 1800 / 1900 MHz GPRS Multi-Slot Class 12 (up to 240 Data transfer kbps), GPRS Mobile Station Class B Data support SMS (text/data) FMB209 | Wiki...
Page 12
Memory 128MB internal flash memory Log Mode, NMEA, LLS, LCD, RFID HID/MF7, PHYSICAL SPECIFICATION RS232 Modes Garmin FMI, TCP ASCII/Binary Dimensions 72,5 x 73 x 27,3 mm (L x W x H) Weight 205 g FMB209 | Wiki...
Output current (U > 3.0 V) Short circuit current (U = 0) DIGITAL INPUT Input resistance (DIN1) 59.9 kΩ Input resistance (DIN2, DIN3) 67.5 kΩ Input voltage (Recommended Operating Conditions) Input Voltage threshold (DIN1) Input Voltage threshold (DIN2, DIN3) FMB209 | Wiki...
Risk of explosion if battery is replaced by an incorrect devices must meet the requirements of EN 60950-1 standard. type. Dispose of used batteries according to the The device FMB209 is not designed as a navigational device for boats. instructions. Battery should not be disposed of with general Do not disassemble the device.
Certification and Approvals FMB209 REACH • FMB209 Declaration of IMEI assignment • This sign on the package means that it is necessary to read the User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki.
More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. FMB209 | Wiki...
