FMB240
Quick Manual
WATERPROOF GPRS/GNSS
v1.3
TRACKER WITH CAN DATA READING
FEATURE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FMB240 and is the answer not in the manual?

Questions and answers

Summary of Contents for Teltonika FMB240

  • Page 1 FMB240 Quick Manual WATERPROOF GPRS/GNSS v1.3 TRACKER WITH CAN DATA READING FEATURE...
  • Page 2: Table Of Contents

    Mounting recommendations with a standard cable ....10 Mounting recommendations with U-type cable ...... 11 LED indications ................12 Characteristics................12 Basic characteristics ..............12 Electrical characteristics ..............14 Safety information ..............16 Certification and Approvals ............17 Wiki FMB240 |...
  • Page 3: Know Your Device

    Know your device Figure 1 – FMB240 device view Wiki FMB240 |...
  • Page 4: Pinout

    Pinout Table 1 FMB240 2x6 socket pinout Pin number Pin name Description VCC (10-30) V DC (+) Power supply (+10-30 V DC). Analog input, channel 2. Input range: 0- DIN 3 / AIN 2 30 V DC / Digital input, channel 3.
  • Page 5: Wiring Scheme

    Wiring scheme Figure 3 FMB240 Wiring scheme Automotive relay Wiki FMB240 |...
  • Page 6: Set Up Your Device

    Please make sure that product casing corner clips are fixed tightly and cable is connected to the device in order to maintain the degree of IP67 protection. Figure 8 Attaching cover back Figure 9 Completely closed device Wiki FMB240 |...
  • Page 7: How To Install Usb Drivers (Windows)

    Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the 1. Power-up FMB240 with DC voltage (10 – 30 V) power supply setup. using supplied power cable. LED’s should start blinking, see “LED indications”.
  • Page 8 Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMB240 configuration using Configurator can be found in our Wiki. Figure 12 Configurator Status window Wiki FMB240 |...
  • Page 9: Quick Sms Configuration

    120 seconds 2006 – Data sending protocol • After successful SMS configuration, FMB240 device will (0 – TCP, 1 – UDP) synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
  • Page 10: Mounting Recommendations With A Standard Cable

    ▬ For better contact scrub paint from the spot where loop is power might be still available on the power wires. going to be connected. Depending on the car model, this may happen in 5 to 30 minutes period. Wiki FMB240 |...
  • Page 11: Mounting Recommendations With U-Type Cable

    Device power wire is designed to be directly connected to ▬ the positive terminal fastener of the vehicle battery • Connecting ground wire ▬ Device ground wire is designed to be directly connected to the negative terminal fastener of the vehicle battery. Figure 13 Device mounting Wiki FMB240 |...
  • Page 12: Led Indications

    Device is not working or Device is in CELLULAR boot mode Technology 2G bands Quad-band 850 / 900 / 1800 / 1900 MHz GPRS Multi-Slot Class 12 (up to 240 kbps), Data transfer GPRS Mobile Station Class B Data support SMS (text/data) Wiki FMB240 |...
  • Page 13 70,5 x 67,0 x 25,6 mm (L x W x H) Digital Input 1, Accelerometer, External Dimensions 85,0 x 67,0 x 25,6 mm (L x W x H) (length Ignition detection Power Voltage, Engine with connector socket) Wiki FMB240 |...
  • Page 14: Electrical Characteristics

    > 3.0 V) Input resistance (DIN2) 38.45 kΩ Short circuit current (U = 0) Input resistance (DIN3) kΩ Input voltage (Recommended Operating Supply Conditions) voltage Input Voltage threshold (DIN1) Input Voltage threshold (DIN2) Input Voltage threshold (DIN3) ANALOG INPUT Wiki FMB240 |...
  • Page 15 Input voltage (Recommended Operating Supply Conditions) voltage Input voltage threshold Sink current CAN INTERFACE Internal terminal resistors CAN bus (no Ω internal termination resistors) Differential input resistance kΩ Recessive output voltage Differential receiver threshold voltage Common mode input voltage Wiki FMB240 |...
  • Page 16: Safety Information

    CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to The device FMB240 is not designed as a navigational device for boats. the instructions. Do not disassemble the device. If the device is...
  • Page 17: Certification And Approvals

    User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki. This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Wiki FMB240 |...
  • Page 18: Warranty

    More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. Wiki FMB240 |...
