Teltonika FMB225 Manual

Hide thumbs Also See for FMB225:

https://wiki.teltonika-gps.com/view/FMB225_Testing_RS-232_and_RS-485_TCP_link_mode

FMB225 Testing RS-232 and RS-485 TCP link

mode

FMB225 Manual

> FMB225 Testing RS-232 and RS-485 TCP link mode

Contents

1 Step 1. Understanding what is FMB225 RS232/RS485 TCP Link mode

2 Step 2. Setting parameters in configurator for TCP Ascii mode test

3 Step 3. Establishing FMB225 test link with server through Hercules

Step 1. Understanding what is FMB225 RS232/RS485 TCP

Link mode

In this mode link with external device (for example PC) using text messages can be established.

FMB225 has to be connected to the external device through RS232 or RS485. Any string of data

coming to RS232 or RS485 will be routed to server (if link is currently active). Messages that are

exchanged between FMB device and server, have to be packed in Codec.12 format. Here for TCP

link establishment we will be using Hercules. For sending messages from external device to server

over FMB225 Terminal will be used.

Step 2. Setting parameters in configurator for TCP Ascii

mode test

First of all, in the FMB225 configurator you have to set parameters for RS232 or RS485 (depends on

which RS232 or RS485 port you are using) in global parameters window.

Table of Contents

Do you have a question about the FMB225 and is the answer not in the manual?

Page 1 Step 2. Setting parameters in configurator for TCP Ascii mode test First of all, in the FMB225 configurator you have to set parameters for RS232 or RS485 (depends on which RS232 or RS485 port you are using) in global parameters window.
Page 2 You can also use RS485 which is also suitable for Ascii TCP Link mode. In order to make a link between FMB225 device and server, Domain and Target Server Port have to be set in the working device profile, GPRS data sending Settings section. When right parameters are set, you can save the configuration to FMB225 device.
Page 3 In this case we have a PC that is considered to be a server and an external device at the same time. When FMB225 is configured and connected to the external device, next what we have to do is to start Hercules (Figure 2) which is in server side and will be used for sending/receiving messages.
Page 4 On terminal you should now receive message: Step 5. Sending from external device to server over Terminal For testing data sending from external device to server, enter text you want to send on Terminal and press send. You can check if data is received to server in Hercules. Sample text: Hello, lets test TCP link mode. Please keep in mind, that special chars (ASCII Names) needs to be marked.
