https://wiki.teltonika-gps.com/view/Template:FMB2_First_start_card
Template:FMB2 First start card
FMB20X Small and professional waterproof tracker with high gain internal GNSS/GSM
antennas, Bluetooth and high capacity internal Ni-MH battery
Contents
1 How to insert Micro-SIM card
2 Cable colors
How to insert Micro-SIM card
1.
Unscrew 6 screws counter-clockwise that are located on the bottom of the device.
2.
Remove the cover.
Insert Micro-SIM card as shown with PIN request disabled or read
3.
enter it later in Configurator. Make sure that Micro-SIM card cut-off corner is pointing
forward to slot.
4.
Connect battery as shown to device.
5.
After configuration, attach device cover and put the screws back in.
6.
Device is ready to be connected.
Micro-SIM card insertion/removal must be performed when device is powered off –
external voltage and battery are disconnected. Otherwise Micro-SIM card might be
damaged or device will not detect it.
Cable colors
Security info
how to
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Teltonika FMB2
Summary of Contents for Teltonika FMB2
- Page 1 Template:FMB2 First start card FMB20X Small and professional waterproof tracker with high gain internal GNSS/GSM antennas, Bluetooth and high capacity internal Ni-MH battery Contents 1 How to insert Micro-SIM card 2 Cable colors How to insert Micro-SIM card Unscrew 6 screws counter-clockwise that are located on the bottom of the device.
- Page 2 PIN NAME DESCRIPTION NUMBER VCC (6-30)V DC (+) Power supply (+6...30 V DC). Black GND (-) Ground. Yellow DIN 1 Digital input, channel 1. White/Green DIN 2 Digital input, channel 2. White DIN 3 Digital input, channel 3. Grey AIN 1 Analog input, channel 1.
