FMB225 First Start
Main Page
>
Advanced Trackers
GNSS/GSM/Bluetooth tracker with internal GNSS, internal GSM antennas, RS232, RS485
interfaces and internal battery
Contents
1 How to insert SIM card and connect battery
How to insert SIM card and connect battery
1.You will receive your device partly closed.
2.Gently remove top and bottom covers.
3.Insert SIM card as shown with PIN request disabled or read our Wiki how to enter it later in
Teltonika Configurator. Make sure that SIM card cut-off corner is pointing outward from slot. SIM
slot 1 is closer to PCB, SIM slot 2 is the top one.
4.Connect battery as shown to device. Position the battery in place where it does not obstruct other
components.
5.After configuration, see "PC Connection (Windows)", attach device top and bottom cover back and
press them twice to the full closure.
6.Make sure that product casing is closed correctly.
This device has an IP67 casing with a two-phase closing, that ensures a reliable protection and ease of use. Please make sure
that product casing corner clips are fixed tightly and cable is connected to the device in order to maintain the degree of IP67
protection.
>
FMB225
> FMB225 First Start
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Teltonika FMB225
Summary of Contents for Teltonika FMB225
- Page 1 3.Insert SIM card as shown with PIN request disabled or read our Wiki how to enter it later in Teltonika Configurator. Make sure that SIM card cut-off corner is pointing outward from slot. SIM slot 1 is closer to PCB, SIM slot 2 is the top one.
- Page 2 Battery placement after complete device disassembling Using double sided tape, stick internal battery to the bottom part of the device case. Battery should be glued approximately 15 millimeters from the bottom wall of the case. Picture on the left. Connect battery to the PCB. Gently place PCB into the bottom case.
- Page 3 Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the setup. Configuration (Windows) At first FMB225 device will have default factory settings set. These settings should be changed according to the user's needs. Teltonika Configurator Main configuration can be performed via software.
- Page 4 Maintenance and etc. FMB225 has one user editable profile, which can be loaded and saved to the device. After any modification of configuration the changes need to be saved to device using Save to device button. Main buttons offer following functionality: Load from device –...
- Page 5 If device has made a record it is sent to the server every 120 seconds After successful SMS configuration, FMB225 device will synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
- Page 6 Device should be mounted with the sticker view to the open sky. FMB225 device should be mounted with the device logo view to the open sky for the best device performance with not less than ¾ of metal free area. FMB225 has IP67 protection class. Top performance is reached if mounted outside of the vehicle.
- Page 7 The device is designed to be mounted in a zone of limited access, which is inaccessible to the operator. All related devices must meet the requirements of EN 60950-1 standard. The device FMB225 is not designed as a navigational device for boats. Precautions Do not disassemble the device.
