Microsemi SmartFusion2 Quick Start Manual page 2

SmartFusion2 DMPM Kit
Kit Contents – SF2-DMPM-KIT
Table 1 • SF2-DMPM Daughter Board Kit Contents
Quantity
1 SF2-DMPM Daughter Card
1 12 V, 5 A AC Power Adapter
1 Any Plug to Grounded 3 pin UK/Hong Kong Plug Adapter
1 Enhanced USB I
1 USB CABLE A-B 3'
50 Mini Jumpers
1 SF2-DMPM-Kit Quickstart Card
K
it Contents – SF2-DEV-KIT
Table 2 • SF2-DEV-KIT Contents
Quantity
1 SmartFusion2 Development Board with M2S050T-FGG896
1 12 V, 6 A AC Power Adapter
1 FlashPro4 Programmer
1 USB A to MicroB Cable
1 USB MicroA to A Cable
50 USB A to Mini-B Cable
1 PCI Edge Card Ribbon Cable
Figure 2 • SF2-DMPM Daughter Board with the SmartFusion2 Development Kit Board
2
2
C Module
Description
Description
