Running the Demo Design With the MPM GUI
Note the COM port assigned to the USB-ISS communications module. Run the MPM GUI, select Data > PC > TestI2C
Dongle. Select the USB-ISS COM port from the Communications > Port drop-down list. Select Test Dongle from the
Activity > Action drop-down list and click the Go button. If the test is successful then you should see the following as
shown in Figure 14, in the Status text box.
Figure 14 • Devantech Robot Electronics USB ISS
2
The MPM reference design demo can be exercised using the MPM GUI communicating with the MPM target I C slave
2
via the Devantech/Robot Electronics USB-ISS I C communications module. Ensure that the USB-ISS hardware and
drivers are installed, configured, and working as described.
