DIN Rail Control Processor
DIN-AP2 Troubleshooting (Continued)
TROUBLE
MSG LED
illuminates.
System locks up. Various.
(Continued on following page)
26 • DIN Rail Control Processor: DIN-AP2
POSSIBLE
CAUSE(S)
Hardware or
software failure,
hardware
incompatibility with
software
definitions or
programming
error.
Operations & Installation Guide – DOC. 6662A
Crestron DIN-AP2
CORRECTIVE
ACTION
Verify that hardware
configuration matches
software configuration.
Use Crestron Toolbox
to display the error log.
Refer to "Error
Message Definitions"
in the latest version of
the Crestron 2-Series
Control Systems
Reference Guide
(Doc. 6256) for more
details.
Press and release the
HW-R button, then
press and hold SW-R
button to bypass
program and
communicate directly
with the processor.
(Refer to
"Troubleshooting
Communications" in
the latest version of the
Crestron 2-Series
Control Systems
Reference Guide (Doc.
6256) for more details.
