Connectors, Controls & Indicators (Continued)
#
4
5
6
7
8
(Continued on following page)
Operations & Installation Guide – DOC. 6662A
CONNECTORS
CONTROLS &
INDICATORS
MSG LED
2
NET
HW-R
SW-R
MEMORY
DIN Rail Control Processor
1
, DESCRIPTION
(1) Red LED, illuminates when
a message is present in the
message log. To view the
contents of the message log,
use Crestron Toolbox™.
(2) 4-pin 3.5 mm detachable
terminal blocks, paralleled
Cresnet port and 24 Volt DC
power input.
Max Wire Size: 1.5 mm
(16 AWG)
Master/Slave selectable
24: Power (24 VDC)
Y: Data
Z: Data
G: Ground
(1) Recessed button reboots
the control system.
(1) Recessed button restarts
the control system program.
(1) MMC compatible card slot
Accepts Multimedia Memory
Cards (MMC) up to 2 GB
DIN Rail Control Processor: DIN-AP2 • 9
