PC4-R PC Control Processor for Crestron Home® OS Product Manual Crestron Electronics, Inc.
Page 2
Security Inc. in the United States and/or other countries. Other trademarks, registered trademarks, and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or photography.
Contents Overview Features Crestron Home® OS PC Control Processor for Crestron Home® OS Crestron Home Setup and Control Apps Integration and Expansion Works with Crestron Home® OS myCrestron Services BACnet Network/IP Support Versatile Installation Specifications Installation In the Box Mount the PC4-R...
Page 4
iv • Contents Product Manual — Doc. 9385A...
The Crestron PC4-R is a PC-based control processor that is embedded with the Crestron Home® operating system. It is designed exclusively to function as the core of a Crestron Home system. The Crestron PC4-R is secured and ready for operation out of the box and only needs power and an Ethernet connection to function.
External 100–240V power pack included Crestron Home® OS Unlock the full potential of a smart home with the Crestron Home® OS. It provides dealers with the ability to deliver a simple and clean user interface that includes sophisticated page designs and dynamic room controls.
The Crestron Home system supports a wide variety of Crestron and third-party devices and controls them all from one user interface. Crestron Home® OS is designed to work with a wide variety of devices to provide control of audio, video, lighting, shading, climate, security systems, door locks, cameras, I/O devices, and third-party devices.
To view the complete list of drivers, visit drivers.crestron.io. Crestron works with our partners to offer the best smart home solution for you and your clients. Some of these partners include 2N video intercom door stations, Amazon® Alexa®...
Storage 256 GB SSD Network Intel® I219-LM 100/1000 Mbps Ethernet Operating System Crestron Home® OS NOTE: The micro computer provides control processor functionality for a Crestron Home system. Typical PC functions are not supported. Communications Ethernet 100/1000 Mbps BACnet™ network/IP...
Page 10
Freestanding, optional VESA® mount and Kensington® lock capabilities Dimensions Height 1.40 in. (36 mm) Width 7.20 in. (183 mm) Depth 7.00 in. (178 mm) Weight 2.87 lb (1.30 kg) Compliance To search for product certificates, refer to support.crestron.com/app/certificates. 6 • PC4-R Product Manual — Doc. 9385A...
Installation This section provides the following information: • In the Box • Mount the PC4-R • Connect the PC4-R Product Manual — Doc. 9385A PC4-R • 7...
In the Box The following items are provided: Qty. Description PC4-R, PC Control Processor for Crestron Home® OS Additional Items Power Pack, 19.5VDC, 100–240VAC 8 • PC4-R Product Manual — Doc. 9385A...
Mount the PC4-R The PC4-R must be installed in a well-ventilated area. The PC4-R can either be placed on a flat, level surface or VESA® mounted using third-party VESA mounting solutions. NOTE: The air intake is located on the front of the device, and air is exhausted out of the rear.
Make all necessary connections to the PC4-R as described below: NOTES: Any connector on the PC4-R that is not listed below is not used. USB ports are used for factory reset and password reset. For details, refer to the Crestron Home® OS Product Manual.
Configuration The PC4-R is configured using the Crestron Home Setup app. Refer to the Crestron Home® OS Product Manual for details. Product Manual — Doc. 9385A PC4-R • 11...
Resources The following resources are provided for PC4-R. NOTE: You may need to provide your Crestron.com web account credentials when prompted to access some of the following resources. Crestron Support and Training Crestron True Blue Support Crestron Resource Library Crestron Online Help (OLH) Crestron Training Institute (CTI) Portal...
Page 17
This page is intentionally left blank. Product Manual — Doc. 9385A PC4-R • 13...
Page 18
Crestron Electronics, Inc. Product Manual — Doc. 9385A 15 Volvo Drive, Rockleigh, NJ 07647 06/23/23 Tel: 888.CRESTRON Specifications subject to Fax: 201.767.7656 change without notice. www.crestron.com...
