14.8 Timer Control


There are 2 sets of ON and OFF timer available to turn the unit ON or OFF at different preset time.

If more than one timer had been set, the upcoming timer will be displayed and will activate in sequence.
14.8.1 ON Timer Control

ON timer 1 and ON timer 2 can be set using remote control, the unit with timer set will start operate earlier than
the setting time.
This is to provide a comfortable environment when reaching the set ON time.

60 minutes before the set time, indoor (at fan speed of Lo-) and outdoor fan motor start operate for 30 seconds to
determine the indoor intake air temperature and outdoor air temperature in order to judge the operation starting
time.

From the above judgment, the decided operation will start operate earlier than the set time as shown below.
Indoor intake air
temperature (°C)
30
25
5 min
14.8.2 OFF Timer Control
OFF timer 1 and OFF timer 2 can be set using remote control, the unit with timer set will stop operate at set time.

14.9 Sleep Mode Operation

This operation provide comfortable environment while sleeping. It will automatically adjust the sleep pattern
temperature during the activation period.
SLEEP
This operation is incorporated with the activation
timer (0.5, 1, 2, 3, 4, 5, 6, 7, 8 or 9 hours).
Start Condition:

Sleep button on remote controller is pressed.

Select OFF timer: 0.5, 1, 2, 3, 4, 5, 6, 7, 8, 9 hours.
Control content:

Sleep function maximum running hour is 9 hours.

When Sleep off timer running out, unit will automatically OFF.

When unit resume from power failure, Sleep function will not resume.

Sleep operation can be set together with Timer operation. Sleep operation has priority over OFF Timer.

Indicator shall be dimmed when this operation is activated.
15 min
10 min
Outdoor air
30 35 (°C)
temperature (°C)
Cooling/Soft Dry
Indoor intake air
temperature (°C)
15
5
35 min
(Cancel)
78
25 min
30 min
Outdoor air
0 5 (°C)
temperature (°C)
Heating
