Connect Water Supply Hose
WARNING!
• To prevent leakage or water damage, follow the instructions in this chapter!
• Do not kink, crush, modify or sever water inlet hose.
• For the model equips hot valve,connect it to hot water tap with hot water supply hose. Energy
consumption will decrease automatically for some program.
Connect the inlet pipe as indicated, There are two ways to connect the inlet pipe.
1. Connection between ordinary tap and inlet hose.
1
Clamp nut
Loosen clamp nut and
four bolts
2. Connection between screw tap and inlet hose.
Tap with threads and inlet hose
Connect the other end of inlet pipe to the inlet
valve at the backside of product and fasten the
pipe tightly clockwise.
Drain Hose
WARNING!
• Do not kink or protract the drain hose.
• Position drain hose properly ,otherwise damage might result of water leakage.
There are two ways to place the end of drain hose:
1. Put the hose into the water drain
Water drain
2
Tighten clamp nut
7
3
Slide bushing
Press slide bushing insert inlet
hose into connecting base
Slide bushing
Special tap for washing machine
Water Inlet valve
2. Connect it to a drain pipe.
ENG
4
Tighten clamp nut
Water supply hose
