Summary of Contents for CA.MI New Askir 118 Basic

  • Page 2: General Warning

    The medical device requires special precautions regarding electromagnetic compatibility and must be installed and used in accordance with the information provided with the accompanying documents: the NEW ASKIR 118 BASIC device must be installed and used away from mobile and portable RF communication devices (mobile phones, transceivers, etc.) that may interference with the said device.

  • Page 3: Technical Characteristics

    CONTRAINDICATIONS - Before using the NEW ASKIR 118 BASIC, consult the instructions for use: failure to read all the instructions in this manual can be harmful for the patient. - The device cannot be used to drain chest fluids; - The device must not be used for suction of explosive, corrosive or easily flammable liquids.
  • Page 4 SYMBOLS Insulation Class II (when used with AC/DC power adaptor or with cigarettes lighter adaptor) CE marking in conformity with EC directive 93/42/CEE and subsequent changes Device approved according to international standards ECE-R10 10R-052527 General warnings and/or specifications Consult the instruction manual before every use Manufacturer: CA-MI S.r.l.

  • Page 5: Accessories Supplies

    ACCESSORIES SUPPLIES DESCRIPTION CODE COMPLETE ASPIRATION JAR 1000ml RE 210001/02 CONICAL FITTING RE 210420 TUBES SET 8 mm x 14 mm 51100/01 HYDROPHOBIC AND ANTIBACTERIAL FILTER SP 0121 SUCTION PROBE CH20 25723 ASKIR 118 SUPPORT BRACKET ASU 118 AC/DC ADAPTER (UE60-140429SPA1) SP 0208/01 POWER SUPPLY CORD FOR AC/DC ADAPTER SP 0020/03...
  • Page 6 PERIODICAL MAINTENANCE CHECKS The NEW ASKIR 118 BASIC suction equipment does not need maintenance or lubrication. It is, however to inspect the unit before each use. With regard to training, given the information contained in the user manual and since it is easy to understand the said device, it doesn’t appear to be necessary.
  • Page 7 low or absent  Connection tubes blocked, connections  Empty the jar, or disconnect the tube from the jar kinked or disconnected  Shut-off valve blocked or and unblock the shut-off valve. The unit twill only work in the upright position damaged ...
  • Page 8 Filter assembling Ensure that the filter is fitted with the Arrows at the patient side. WARNING: The inside of the medical device must be regularly checked for the presence of liquids or other visible contamination (secretions). If liquids or other visible contamination are present, the medical device must be replaced immediately due to the risk of insufficient vacuum flow.
  • Page 9 PROXIMITY FUNCTIONS:  Pressing the "Proximity" (Lights BLUE LED) is activated on / off the motor by an infrared proximity sensor that detects the presence of the operator's hand from a few inches away. This allows the operator to use the device without touching or focus on pressing the button.
  • Page 10 The support bracket of the NEW ASKIR 118 BASIC device consists of a plastic part (ABS) and a seal hook, which allows the suction unit to be fixed safely and easily. The figure below shows the bracket complete in all its parts.
  • Page 11 Always make sure that the fixing screws are tightened correctly;  Fit the suction unit in the bracket as indicated in Chapter "Securing the NEW ASKIR 118 BASIC suction device;  Visually check (as in TAB.II) that the LED lights up to indicate that the internal battery on the central panel is recharging.

  • Page 12: Risk Of Electromagnetic Interference And Possible Remedies

    The surgical aspirator NEW ASKIR 118 BASIC is intended for use in the electromagnetic environment specified below. The customers or the user of the surgical aspirator NEW ASKIR 118 BASIC should assure that it’s used in such an environment. Emissions test...
  • Page 13 Guidance and manufacturer’s declaration – Immunity Emissions The surgical aspirator NEW ASKIR 118 BASIC is intended for use in the electromagnetic environment specified below. The customers or the user of the surgical aspirator NEW ASKIR 118 BASIC should assure that it’s used in such an environment.

  • Page 14: Warranty Conditions

    WARRANTY CONDITIONS This product is guaranteed for a period of 24 months from the date of purchase. The warranty includes the repair or replacement of defect spare parts free of charge, if the defect has been clearly described by the customer and determined by technical service. Inspections on the part of the seller, performed at the request of the customer and intended to determined wjether the device is fully functional, are not covered by the free-of-charge warranty service.
