500ACO2-HD/SD Dual HD/SD SDI Auto Changeover
TABLE OF CONTENTS
Revision 1.4
Frame Manual
500ACO2-HD/SD
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for evertz exponent 500ACO2-HD/SD
Summary of Contents for evertz exponent 500ACO2-HD/SD
-
Page 1: Table Of Contents
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover TABLE OF CONTENTS OVERVIEW............................1 INSTALLATION..........................2 2.1. CONNECTING THE GENERAL PURPOSE INPUTS AND OUTPUTS........3 SPECIFICATIONS..........................4 3.1. SERIAL VIDEO INPUT ......................4 3.2. SERIAL VIDEO OUTPUTS......................4 3.3. GENERAL PURPOSE INPUTS AND OUTPUTS ..............5 3.4. ELECTRICAL ..........................5 3.5. - Page 2 Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover VISTALINK™ REMOTE MONITORING/CONTROL ................12 7.1. W LINK™? ......................12 HAT IS ISTA 7.2. V LINK MONITORED PARAMETERS ................12 ISTA 7.3. V LINK CONTROLLED PARAMETERS ................13 ISTA 7.4. V LINK TRAPS .......................13 ISTA Figures Figure 1: 500ACO2-HD/SD Block Diagram ......................
- Page 3 Feb 06 Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of Evertz products are for informational use only and are not warranties of future performance, either express or implied.
- Page 4 Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover This page left intentionally blank 500ACO2-HD/SD Revision 1.4...
-
Page 5: Overview
500ACO2-HD/SD Dual HD/SD SDI Auto Changeover OVERVIEW The Evertz 500ACO2-HD/SD dual SDI Autochangeover is designed to provide extension to the 5600ACO for HD or SD SDI, DVB-ASI, AES audio and analog video. The unit can also be operated as a standalone changeover unit with two independent 2X1. -
Page 6: Installation
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover INSTALLATION The 500ACO2-HD/SD comes with a companion rear panel overlay that can be placed over the rear panel BNC connectors to identify their function. For information on inserting the module into the frame see the 500FR chapter section 3. -
Page 7: Connecting The General Purpose Inputs And Outputs
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover a small screwdriver. The removable part of the terminal strip is then inserted into the rear panel. Please refer to Figure 3 for additional information on installing the panel adapter. 1. Using a Philips screwdriver, remove the screw below the slot where you want to install the panel adapter. -
Page 8: Specifications
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover + 5 VDC 1 K ohm internal circuit 10 Ohm GPI Input Figure 4: GPI Circuitry The outputs are internally pulled up to 5 volts. Care must be taken to limit the load to 0.1W so there is no affect on the power supply source in the frame. -
Page 9: General Purpose Inputs And Outputs
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover 3.3. GENERAL PURPOSE INPUTS AND OUTPUTS Type: Inputs: Opto-isolated input with internal pull-up to + 5volts. Outputs: Normally 10K internal pull-up to + 5volts. Ground to rear panel when relay is in active position. -
Page 10: Signal Present Leds
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover 4.2. SIGNAL PRESENT LEDS There are four small green LEDs that indicate the presence of valid input signal. 4.3. INPUT SELECTED LEDS There are four small green LEDs that indicate the current selected input for each 2X1 unit. MODES OF OPERATION The 500ACO2-HD/SD is equipped with a 4 position DIPswitch for selection of various modes of operations. -
Page 11: Aco Extension Mode
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover 5.1. ACO EXTENSION MODE When the 500ACO2-HD/SD operated in ACO Extension mode it provides the capability to extend the changeover capabilities of the 5600ACO to switch HD or SD SDI, DVB-ASI, AES audio or additional analog video. -
Page 12: Gpi Control Mode
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover 5.2. GPI CONTROL MODE In the GPI control mode, the output of each 2x1 can be independently selected using the two available GPI inputs, as described in Table 3 and Table 4. Please refer to section 2.1 for details on GPIO connections. -
Page 13: 5.3.1. Dvb-Asi Exclusive Mode
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover GPI input 1 GPI input 2 Output of ACO1, and ACO2 Current output High High High High Current output Table 8: GPI inputs in Autochangeover mode 5.3.1. DVB-ASI Exclusive Mode While in Auto Changeover mode, activating the DVB-ASI Exclusive mode will force the 500ACO2-HD/SD to only validate DVB-ASI signals. -
Page 14: Manual Dip Switch Control Mode
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover GPI input 1 GPI input 2 Output of ACO1, and ACO2 Current output, re-enable autochangeover High B, disable autochangeover High A, disable autochangeover High High Current output, re-enable autochangeover Table 11: GPI inputs in Autochangeover mode with GPI Override 5.4. -
Page 15: Jumpers And User Adjustments
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover JUMPERS AND USER ADJUSTMENTS watchdog enable Input 1 A Selected Input 1 B Selected Input 2 A Selected Input 2 B Selected Input 1 A Present Input 1 B Present Upgrade Jumper upgrade Input 2 A Present Input 2 B Present... -
Page 16: Vistalink™ Remote Monitoring/Control
2. Managed devices (such as 500ACO2-HD/SD), each with a unique address (OID), communicate with the NMS through an SNMP Agent. Evertz VistaLINK™ enabled 500 series modules reside in the 3RU 500FR MultiFrame and communicate with the manager via the 500FC VistaLINK™ frame controller module, which serves as the Agent. -
Page 17: Tm Controlled Parameters
Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover Signal Presence 2B Indicates the presence of a valid signal on input 2B Signal Presence 2A Indicates the presence of a valid signal on input 2A Signal Presence 1B Indicates the presence of a valid signal on input 1B Signal Presence 1A Indicates the presence of a valid signal on input 1A Signal Standard 2B... - Page 18 Frame Manual 500ACO2-HD/SD Dual HD/SD SDI Auto Changeover This page left intentionally blank 500ACO2-HD/SD- Revision 1.4...
