ASSEMBLY INSTRUCTIONS

Step 1: Remove the main frame out of the carton.
Step 2: As illustrated below, hold the column with both hands and gently pull upwards. Fix the column on the
main frame with the round knob (#6).
Step 3: Then use 8# (M6*15) to lock the 7# mobile phone holder on the column corresponding to the direction
indicated by the icon arrow. In terms of location, when you need to put the mobile phone on the 7#
mobile phone holder, you can stick the 9# mobile phone anti-slip mat on the 7# mobile phone holder
to prevent the phone from falling.
SM-2P
Safety key
SM-2P
8
7
9
~ 4 ~
