ASSEMBLY INSTRUCTIONS
Step 1: Lift the main frame out of the carton and open the cable ties that bind the frame.
Step 2: Unfold the frame: When unfolding, please support the column according to the N figure and gently pull it up in
the direction indicated by the arrow in the diagram below and fix it on the sheet metal part of the base with
D#M8*45 screws.
Step 3: Unfold the electronic watch frame in the direction of the arrow first, and then fix the electronic watch frame on
the column with D#M8*45 screws (2 pcs), G#M8 spacers (2 pcs), F#M8*15 (2 pcs) on.
~ 3 ~
