Summary of Contents for HOMCOM A90-250V70
- Page 1 INan009_UK A90-250V70 Electric Treadmill User Manual IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY INSTRUCTION...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION ............................1 PACKAGE SPECIFICATIONS ..........................2 ASSEMBLY INSTRUCTIONS ..........................3 ELECTRONIC CONTROL INSTRUCTIONS ......................5 MAINTENANCE INSTRUCTIONS .......................... 8 MAINTENANCE INSTRUCTIONS .......................... 8 LUBRICANTS ................................9 ERRORS AND TROUBLE SHOOTING ....................... 10 EXERCISE GUIDELINES ............................11 WARM UP EXERCISES ............................12 Thanks for choosing this home electric treadmill. -
Page 3: Safety Information
SAFETY INFORMATION Please read all contents of this manual carefully before use for the safety of all users. We are not liable for any injuries because of improper operation. RISK Please do not use the heart rate device together with other wireless heart monitors as it can cause an electrical interference. -
Page 4: Package Specifications
PACKAGE SPECIFICATIONS Screw Bag ~ 2 ~... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS Step 1: Lift the main frame out of the carton and open the cable ties that bind the frame. Step 2: Unfold the frame: When unfolding, please support the column according to the N figure and gently pull it up in the direction indicated by the arrow in the diagram below and fix it on the sheet metal part of the base with D#M8*45 screws. - Page 6 Step 4: As shown in Figure W below, lock the side cover with Part J (#ST4*15) screws on the column and the bottom frame, and lock the bolts on the bottom frame as illustrated in diagram Y below. Step 5: Folding the Treadmill: When you need to transport or not use this product for a long time, please fold it up as shown in the figure below: ~ 4 ~...
-
Page 7: Electronic Control Instructions
ELECTRONIC CONTROL INSTRUCTIONS 4.1 The appearance of the electronic watch is shown in the image below. 4.2 Start up. Countdown starts after 3 seconds. 4.3 Number of programs 3 manual programs, 12 automatic programs, and 1 FAT program. 4.4 Safety lock function When the safety lock is removed, the "E7"... - Page 8 4.5.5 Speed shortcut button: Press the speed shortcut keys 2KM, 4KM, 6KM, 8KM, 10KM, 12KM on the display control panel to directly adjust to the corresponding speed. 4.5.6 Music control button When connecting with Bluetooth to play music, you can increase or decrease the volume through the volume plus and minus buttons on the panel.
- Page 9 Time slot Set time / 10 = run time of each time slot Program SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED SPEED P10 SPEED P11 SPEED P12 SPEED 3 modes setting program. The countdown time is initially set to 10:00 minutes, the setting range is 5:00---99:00 minutes, and the step is 1:00.
-
Page 10: Maintenance Instructions
01 Man 02Women 10 - 99 Height Weight FAT ≤19 Underweight (20---25) Normal weight (25---29) Overweight ≥30 Obese 4.11 Other 4.11.1 When a countdown parameter is finished running, the display shows END, and an alarm will sound for 0.5 seconds every 2 seconds until the treadmill stops and the alarm stop, and then treadmill return to manual mode. -
Page 11: Lubricants
The running belt has been adjusted before leaving the factory, but after use, the running belt will be stretched and will deviate from the centre position, causing the running belt to rub the side bars and the rear cover and damage it. -
Page 12: Errors And Trouble Shooting
ERRORS AND TROUBLE SHOOTING The electronic table displays the error message codes: FAULT CODE ISSUE SOLUTION ✓ Checking whether the communication line is loose, dropped, or damaged. The display board does not ✓ Check or replace the electronic watch board. have a signal ✓... -
Page 13: Exercise Guidelines
Common problems and troubleshooting methods. 7.2.1 Some or all the buttons are not working well. ➢ Uncover the upper case of the electronic watch and test whether the buttons are working. ➢ Check or replace the electronic board. ➢ Check the button can be worked after the power is turned back on. 7.2.2 The electronic watch has no display. -
Page 14: Warm Up Exercises
WARM UP EXERCISES Warm-up and soothing exercise: A successful exercise program must include warm-up, aerobic and soothing exercises. The number of exercises should start with at least two or three times a week, increasing to four or five times a day after a few months. Warm-up is an important part of your fitness routine and should not be skipped.
