B.13 Power LED and Keylock Connector
(CN16)
You can use an LED to indicate when the CPU card is on. Pin 1 of
CN16 supplies the LED's power, and Pin 3 is the ground.
You can use a switch (or a lock) to disable the keyboard so that the
PC will not respond to any input. This is useful if you do not want
anyone to change or stop a program which is running. Simply
connect the switch from Pin 4 to Pin 5 of CN16.

Table B-13: Power LED and keylock connector (CN16)

Pin
1
2
3
4
5
B.14 External Speaker Connector (CN17)
The CPU card has its own buzzer. You can also connect it to the
external speaker on your computer chassis.

Table B-14: External speaker (CN17)

Pin
1
2
3
4
PCA-6178 User's Manual
114
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com
Function
LED power (+5 V)
NC
GND
Keyboard lock
GND
Function
+5 V
CC
GND
Internal buzzer
Speaker out
