1.5
Connectors on the PCA-6178 board link it to external devices such as
hard disk drives and a keyboard. In addition, the board has a number
of jumpers used to configure your system for your application.
The tables below list the function of each of the board jumpers and
connectors. Later sections in this chapter give instructions on setting
jumpers. Chapter 2 gives instructions for connecting external devices
to your card.

Table 1-1: Jumpers

Label
J1
J2
J3
SW1
SW2
Artisan Scientific - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisan-scientific.com

Jumpers and Connectors

Function
CMOS clear
Watchdog timer output
DiskOnChip
CPU clock ratio setting
CPU type select
® 2000 address setting
Chapter 1 Hardware Configuration
9
