Modine Manufacturing VFV Series Installation And Service Manual page 16

DIMENSIONAL DATA
Figure 16.1 - Dimensions - 21-7/8" Depth - Floor Mounted Unit
6.36
( 161.7 )
(TYP)
11.50
( 292.1 )
(TYP)
2.66
( 67.4 )
(TYP)
1.09
( 27.7 )
(UNIT SHOWN
WITH END
PANELS)
CONTROL
PANEL
FRONT SERVICE
PANELS
13.00
( 330.2 )
18.20
(TYP)
( 462.2 )
(TYP)
(4) - Ø.88 (22.4)
MOUNTING HOLES (TYP)
4.12
( 104.7 )
j Dimensions shown are inches (mm).
Table 16.1 - Unit Width Dimensions
Model Size
W1
750
62" (1574.8mm)
1000
74" (1879.6 mm)
1250
86" (2184.4 mm)
1500
98" (2489.2 mm)
16
10.00
( 254 ) REMOVABLE BOTTOM PANEL
(TYP) (EACH END)
W3
TOP VIEW
6.60
( 167.7 )
W1
12.34
( 313.5 ) (TYP)
FRONT VIEW
6.61
( 167.9 )
(TYP)
PIPE TUNNEL
W2
OUTSIDE AIR
OPENING
REAR VIEW
Dimensions (inches)
W2 W3
36" (914.4mm) 30" (762mm)
48" (1219.2 mm) 42" (1066.8 mm)
60" (1524 mm) 54" (1371.6 mm)
72" (1828.8mm) 66" (1676.4m)
5.36
( 136 )
21.83
(554.5)
1.78
BARSTOCK ( 45.2 )
DISCHARGE GRILLE
MOTOR
2.27
( 57.7 )
ELECTRICAL
BOX
3.18
( 80.7 )
RECESSED RETURN
AIR/KICK PANEL
10.56
( 268.2 ) (TYP)
2.56
( 65 ) (TYP)
7.00
( 177.8 ) (TYP)
21.22
( 538.9 )
(TYP)
1.00
CONDENSATE LINE
( 25.4 )
OPENING (x2)
14-500.7
21.83
( 554.6 )
7.67
( 194.8 )
3.10
( 78.7 )
9.06
( 230.1 )
PIPE
( 416.6 )
TUNNEL
5.15
( 130.8 )
18.90
( 480.1 )
RIGHT SIDE VIEW
PIPING ACCESS
OPENING
(EACH END)
16.40
27.08
( 687.9 )
30.26
( 768.6 )
