Directed DIRECTECHS DB3 Installation Manual page 9

Module
Conn./Pin Color
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
Input 10-pin black connector (H3)
Module
Conn./Pin Color
H3/1 Green
H3/2 Blue
H3/3 Red/White
H3/4 White/Violet
H3/5 Violet/Black
H3/6 White/Black
H3/7 Pink/White
H3/8 Violet
H3/9 Pink
H3/10 Blue/White
D2D 4-pin white connector (H4)
Module
Conn./Pin
H4/1
H4/2
H4/3
H4/4
RF 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
9 403.KIA10 1.10 2023 Kia Carnival (Smart Key)
©2023 Directed. All rights
Description
No Connection
Immo. Data (conn. side)
No Connection
Description
No Connection
No Connection
No Connection
No Connection
No Connection
[1]
(-) Hood Input
No Connection
No Connection
No Connection
No Connection
Color
Blue
Black
Green
Red
Color
N/A
N/A
Connects To
Wire Location
No Connection
Driver Kick, white 55 pin plug (EM11), pin 16
No Connection
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
The installation of an aftermarket hood pin is ONLY required on vehicles that
are NOT equipped with a factory hood pin or NOT supported in data.
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color
Data White/Black
(+/-) Wire Color
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
Description
RF Loop
RF Loop
