6.5 Operating parameters

The device allows the coniguration of the parameters listed in the following table.
The parameters marked with the symbol
Settings remain active even after the device has been turned of and they are stored in non-volatile memory.
PRINTER EMULATION
PRINT MODE
AUTOFEED
CHARS / INCH
COLUMNS 22 cpi
CODE TABLE
D
are the default values.
Available emulations for the device:
CUSTOM/POS
D
PLUS
FH190
Printing mode:
Normal D = enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
Setting of the Carriage Return character:
CR disabled D = Carriage Return disabled
CR enabled = Carriage Return enabled
Font selection:
D
A = 13 cpi, B = 17 cpi
A = 17 cpi, B = 22 cpi
A = 22 cpi, B = 17 cpi
CPI = Characters Per Inch.
Number of columns to use when the 17x22 cpi font is in use (see parameter "Chars / Inch"):
D
40 columns
42 columns
The parameter is printed only with PLUS or FH190 emulation enabled.
To modify the parameter, set the PLUS or FH190 emulation (see parameter "Printer
Emulation") and the 17x22 cpi font (see parameter "Chars / Inch").
Identiier number of the character code table to use.
See paragraph 9.8 to learn about the character tables corresponding to the identiication
numbers set with this parameter.
The character tables set with this parameter are the same set with the command 0x1B
0x74 (refer to the commands manual of the device).
