1
PANEL DESCRIPTION
RX SPEAKER KEY
Push to turn the RX speaker function ON or OFF.
When the RX speaker function is turned ON, the received
audio can be heard via the external speaker.
• This function is available when the external speaker is additionally
connected.
• This function is useful when you are out of the vehicle.
• The audio output level is linked to the transceiver's volume control.
LIGHT KEY
Push to turn the transceiver's backlight ON for about 5 sec.
when the backlight function is turned OFF in user set mode.
LOCK KEY
Push and hold to electronically lock all programmable keys
except the following:
[Moni(Audi)], [Light], [Lock], [Call] (incl. Call A and Call B),
[Emergency Single], [Surveillance], [Lone Worker] and [OPT 1/2/3].
LONE WORKER KEY
Push to turn the Lone Worker function ON or OFF.
• If the Lone Worker function is activated, the Emergency function is
automatically turned ON after the specified time period has passed
with no operation is performed.
HIGH/LOW KEY
Push to select the transmit output power temporarily or per-
manently, depending on the pre-setting.
• Ask your dealer for the output power level for each selection.
5
TONE/RAN CH SELECT KEY
➥ While in analog mode operation, push to enter the con-
tinuous tone channel selection mode. Then select the
desired tone frequency/code setting with [CH Up] or
[CH Down]. After the selection, push this key again to set.
➥ While in digital mode operation*, push to enter the RAN
channel selection mode. Then select the desired RAN set-
ting with [CH Up] or [CH Down]. After the selection, push
this key again to set.
➥ While in mixed (digital and analog) mode operation*, push
to enter the continuous tone channel selection mode.
Then select the desired tone frequency/code setting with
[CH Up] or [CH Down]. After the selection, push this key
to set. After that, the RAN channel selection screen ap-
pears. Select the desired RAN setting with [CH Up] or
[CH Down]. After the selection, push this key again to set.
* Digital and mixed (digital and analog) mode operations are avail-
able only when the optional UT-126H
is installed. Ask your dealer for details.
LATOR UNIT
C.TONE CH ENT KEY
Push to enter the continuous tone channel selection mode.
Then select the desired tone frequency/code setting with
[CH Up] or [CH Down]. The selected channel remains set as
the continuous tone channel until another channel is desig-
nated as such.
-
DIGITAL MODULATOR / DEMODU
