TG-2022
SUPERBRAVA
Electric stretcher
Backrest Articulation/Shock Position
Footrest Articulation/Shock Position
Recommended operatives required to load / unload an
Recommended/Compatible fixation system
Maximum unassisted load
Standards
Wheels diameter
Total Length
Total Width
Maximum and minimum height
Loading Height
occupied stretcher
320Kg
Weight
78 Kg
UNE-EN-1865-2
UNE-EN-1865-3
EN-1789+A1
UNE-EN 60601-1 / UNE-EN 61000-6
UL-1642
De 0º a 80º
Double articulation
150 mm
1
2090 mm
590 mm
2
347 mm-1240 mm
3
Máx. 1090 mm
1 operative, or 2 if the stretcher were occupied by a
larger sized patient.
Rail SUPERBRAVO 1 and SUPERBRAVO 2
QUICK GUIDE
TG-2022 SUPERBRAVA
+34 93 715-86-72
info@kartsana.com
www.kartsana.com
