How to install the motion control board in the PC

The following are required:
•
Motion control board APCI-8001or APCI-8008
•
TOOLSET CD
4.1

Installing the xPCI-800x controller

•
Switch the PC off
•
Electrostatically discharge yourself
•
Insert the board vertically from above into the selected PCI slot
(Ensure that you do not touch the gold contacts, if necessary the contacts can first be cleaned with
alcohol)
•
Switch the PC on and start Windows.
Supply voltages of 3.3 V and 5 V must be available at the PCI bus of the target system (PC
motherboard). This can be identified using the diagnosis LEDs listed below, after switching on the
PC. All diagnosis LEDs are on the back (soldered side) of the xPCI-800x controller, on the top edge
of the board. These are small SMD (surface-mounted) light-emitting diodes. See also the sub-
component insertion diagram on the next page.
Device
APCI-8001
APCI-8008
CPCI-8004
LED Function
D27 PC supply voltage 5 V (1st LED seen from the
board holder). Must be lit up.
D28 PC supply voltage 3.3 V (2nd LED seen from the
board holder). Must be lit up.
D32 Flashes, showing that the monitor program is
running (1st LED on the side facing away from the
board holder). Must flash when the PC is
switched on.
D50 PC supply voltage 5 V (1st LED seen from the
board holder). Must be lit up.
D51 Internal supply voltage 3.3 V (2nd LED seen from
the board holder). Must be lit up.
D57 Flashes, showing that the monitor program is
running (1st LED on the side facing away from the
board holder). Must flash when the PC is
switched on.
D34 PC supply voltage 5 V (1st LED seen from the
board holder). Must be lit up.
D35 PC supply voltage 3.3 V (2nd LED seen from the
board holder). Must be lit up.
D39 Flashes, showing that the monitor program is
running (1st LED on the side facing away from the
board holder). Must flash when the PC is
switched on.
