10
2.3
Special notes for the CPCI-8004
Data exchange between the CPCI-8004 boards and peripherals takes place via a shielded cable. This cable
should be connected to the 78-pin SUB-D connector on the CPCI-8004.
The CPCI-8004 also has digital outputs for processing 24 V signals. An external 24 V supply voltage is
required to operate these outputs.
2.4
Limits of use
By using the boards in a PC, the resistance to interference and emission values of the PC may change.
Increased emissions or reduced resistance to interference can mean that the conformity of the system is no
longer ensured.
EMERGENCY STOP functions must not be taken over by any of the above-mentioned modules.
The EMERGENCY functions must be protected separately. This protection must not be influenced by the
boards and the PC.
The board must remain in its anti-static packaging until it is installed.
The warranty claim becomes invalid if the identification numbers are deleted or changed.
2.5
USERS
2.5.1
Qualification
The following activities must only be executed by trained electronics employees:
•
Installation
•
Commissioning
•
Operation
•
Maintenance
2.5.2
Personal protection equipment
Please note the national regulations regarding:
•
Accident prevention
•
Installation of electrical and mechanical equipment
•
Electromagnetic compatibility (EMC).
CM / C
M
OMMISSIONING
ANUAL
