- Page 1 BIOCLIMATIC PERGOLA INSTRUCTION MANUAL 4 PILLARS...
- Page 2 THANK YOU FOR PURCHASING ® OUR MIRADOR BIOCLIMATIC PERGOLA! This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - List of Parts - Installation - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly and Disposal of the Product - Certification Information... -
Page 4: Before Assembling Your Pergola
BEFORE ASSEMBLING YOUR PERGOLA Please read all the instructions carefully before you begin, and follow the steps in the order they are presented. Make sure you have all the tools required for assembling your pergola In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided. - Page 5 Check to ensure there are no missing parts Before you begin installation, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please contact customer service before beginning the installation .
-
Page 6: Important Safety Advice
IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the pergola, it is important to follow the safety guidelines below. If using power tools or The pergola must be Always wear appropriate Work well away from power Make sure the pergola a ladder, always follow positioned and fixed on flat... - Page 7 Installation of non-Mirador Put the louvers into the After prolonged use we branded accessories will void Do not attempt to assemble vertical position during recommend you check all Please recycle packaging the product warranty and the product if you are tired, or...
-
Page 8: List Of Parts
LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. Length PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Width Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA. - Page 9 Part Name 3m/10ft. 3.6m/12ft. Corner pillar cover 4 pcs 4 pcs Screw ST5.65x45mm 24+2 pcs 24+2 pcs Screw M5x12mm 76+4 pcs 92+5 pcs Screw 4.2x25mm 76+4 pcs 92+5 pcs Screw 5.5x19mm 12+2 pcs 12+2 pcs Crank coupler 1 pcs 1 pcs Anchor bolt M8x80mm 16 pcs 16 pcs...
- Page 10 Part Name 3m/10ft. 3.6m/12ft. Louver 19 pcs 23 pcs Louver end cap 37+2 pcs 45+2 pcs Louver end cap 1 pcs 1 pcs with control arm Connecting strip 2 pcs 2 pcs Cotter pin 38+6 pcs 46+7 pcs...
-
Page 11: Installation
INSTALLATION 4 PERSONNEL REQUIRED 1. Set up the corner pillars Installation Video Slide the foot plate cover with its wide opening facing outwards on the straight end of the corner pillar Push the foot plate against the straight end of the corner pillar It only fits in one direction and in one position. - Page 12 2. Connect the side beam with gearbox to the corner pillars Using a hex key (large) , slightly loosen the 8 built-in screws at both ends of the side beam with gearbox .(4 on each side) Lay two corner pillars and place the side beam with gearbox on the floor,...
- Page 13 Tighten the screw with the hex key 3. Connect the side beam without gearbox to the remaining two regular corner pillars Repeat steps to connect the beam without gearbox with the remaining two corner pillars...
- Page 14 4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 4 PERSONNEL REQUIRED Only use ladders suitable for this kind of installation work. Stand the two structures built during steps 2 and 3 in an upright position, and place them at one end beam length...
- Page 15 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the hex key provided Install the other end beam following steps...
- Page 16 5. Check the alignment of the frame and the distance between the corner pillars You are now almost done installing the main frame of the pergola. Please double check to ensure all beams and pillars have been installed and fitted correctly. You may have to unscrew certain bolts during this step.
- Page 17 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. Size (m/ft) (mm) (inch) 3x3/10x10 3966.2 156.1 3x3.6/10x12 4418.7...
- Page 18 6. Install Crank Gearbox Locate the gearbox on the side beam with gearbox Unscrew and remove the small screw from the crank connector. Insert the crank coupler into the crank connector and re-insert and tighten the small screw.
- Page 19 Insert the end of the crank into the crank coupler , and turn until the crank locks firmly in place...
- Page 20 7. Install the louvers, and connecting strips Prepare the driving louver: select one of the louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver.
- Page 21 Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
- Page 22 Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft support brackets on both ends of each louver . Use two screws each and secure them with a cordless screwdriver. Repeat this step for all louvers. Part \ Length 3m/10ft.
- Page 23 Take the connecting strip . Attach it to each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. Repeat this step for all cotter pins.
- Page 24 8. Secure the corner pillar covers To install the pillar cover, fix a pillar cover to the top of each corner with three screws each . Fix them using a cordless screwdriver. x 12...
- Page 25 9. Secure the corner pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the corner pillars with the four foot plates , drill through each hole with a hammer...
- Page 26 10. End of installation...
-
Page 27: Operating Your Pergola
OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle anti-clockwise. -
Page 28: Problem Solving, Care & Maintenance
PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or Action to take Check if any of the louvers are deformed. If this is the case, replace them. If the Abnormal noise occurs during the rotation of the louver(s). louvers are not deformed but they are colliding with one another, replace the beam. - Page 29 GENERAL CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture For more soiled areas, rinse the Air dry or wipe with a soft clean pergola and will require periodic and a soft clean cloth to clean surface with clean water from top cloth cleaning...
-
Page 30: Warranty & Complaints Procedure
WARRANTY & COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador® sales representative. Complaints procedure: • The complaint must include an order number or transaction number. • The complaint must include a detailed description of the defect, the name of the company which installed the product and the date when the defect was discovered. -
Page 31: Disassembly And Disposal Of The Product
DISASSEMBLY AND DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling. -
Page 32: Certification Information
CERTIFICATION INFORMATION Declaration of performance (DOP) EC Declaration of Conformity... - Page 33 Declaration of performance (DOP) Reference no. DOP0002 Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 80 Solid AxBm, 80 AxBm, AxB: 3x3, 3x5 88 Solid AxBm, AxB: 88 Basic AxBm, 88 S AxBm, AxB: 3x3, 3x3.6, 3x6...
- Page 34 EC Declaration of Conformity Product name and type Mirador Pergola and Mirador Wall Pergola / pergola awning Model name/ Unique identification code of the product: 111 Deluxe e-Motion, 111 Deluxe Edge e-Motion, 111 Deluxe R e-Motion, 111 Infinite e-Motion, 111 Infinite Edge e-Motion...
- Page 35 Printed on 100% post-consumer recycled paper...
