  • Page 1 111 Gazebo LED INSTRUCTION MANUAL...
  • Page 2 THANK YOU FOR PURCHASING OUR MIRADOR GAZEBO LED This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your gazebo, to ensure it brings you many years of use and enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Gazebo - Important Safety Advice - Technical Data - List of Parts - Assembly 4 pillar - Assembly 6 pillar - Operating Your Gazebo - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly &...

  • Page 4: Before Assembling Your Gazebo

    BEFORE ASSEMBLING YOUR GAZEBO Please read all the instructions carefully before you begin, and follow the steps in the order they are presented. Make sure you have all the tools required for assembling your gazebo: In order to assemble your gazebo safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Check to ensure there are no missing parts: Before you begin assembly, please check that you have all the parts required to assemble your gazebo. Please also carefully check that the quantity of parts match with that of the model you have purchased. (4-pillar or 6-pillar). If any parts are missing, please refer Warranty &...

  • Page 6: Important Safety Advice

    Approved Electrical installation may only Mirador electric gazebos After prolonged use we Make sure all electrical be carried out by certified should only be connected...
  • Page 7 Installation of non-Mirador branded accessories will void Do not attempt to assemble Do not touch moving parts Keep the remote control the product warranty and Do not climb on the roof. the product if you are tired, or during operation.
  • Page 8 WARNING: When using outdoor use portable lighting products, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following: WARNING WARNING WARNING WARNING Use only outdoor extension Material may become brittle Do not mount or support Risk of Fire and Electric cords, such as type SW, SOW,...

  • Page 9: Technical Data

    TECHNICAL DATA Input Voltage 24V DC Control box Ingress Protection Rating IPX5 Input Voltage 24V DC Light LED strip Ingress Protection Rating IP68 Input Voltage 110 to 240V Power supply Ingress Protection Rating IP67 Maximum Power 250VA Control Method Remote Control Control Frequency Band 2400MHz-2483.5MHz...

  • Page 10: List Of Parts

    LIST OF PARTS The quantities of parts are listed below for the 4-pillar and 6-pillar models. Please carefully check that the quantity of parts match with that of the model you have purchased. PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Please check before proceeding.
  • Page 11 4-pillar 6-pillar 4-pillar 6-pillar Part Name Part Name Foot plate cover 4 pcs 6 pcs Plastic pin 4+6 pcs 4+12 pcs Foot plate 4 pcs 6 pcs Control box 1 pcs 1 pcs Corner pillar cover 3 pcs 3 pcs Canopy 1 pcs 1 pcs...

  • Page 12: Assembly 4 Pillar

    ASSEMBLY 4-pillar For assembly of the 6-pillar model, please go directly to page 33. Assembly Video...
  • Page 13 1. Set up the corner pillars Fix the cable flange with screws onto the cabled corner pillar , and make sure the cable is hanging outside. Slide the foot plate cover with its wide opening facing outwards on the straight end of the cabled corner pillar...
  • Page 14 Push the foot plate against the straight end of the cabled corner pillar . It only fits in one direction and in one position. If in doubt, rotate it until it fits easily. Screw in the foot plate with 6 screws using a cordless screwdriver.
  • Page 15 2. Connect the side beam to the cabled corner pillar and a standard corner pillar Using a hex key (large) , slightly loosen the 4 built-in screws at the same end of the side beam Slide the side beam into the grooves of the cabled corner pillar in such a way that the slot nuts of the side beam...
  • Page 16 Fix the side beam tightly onto the cabled corner pillar with the four built-in screws, using the hex key provided. Repeat steps to connect the other end of the side beam with one of the standard corner pillars...
  • Page 17 3. Connect the side beam to the remaining two standard corner pillars Repeat steps to connect the beam with the remaining two corner pillars...
  • Page 18 4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 4 PEOPLE REQUIRED Only use ladders suitable for this kind of installation work. Stand the two structures built during steps 2 and 3 in an upright position, and place them at one end beam...
  • Page 19 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the ratchet hex wrench provided. Assemble the other end beam repeating steps...
  • Page 20 5. Check the alignment of the frame and the distance between the corner pillars You are now almost done assembling the main frame of the gazebo. Please double check to ensure all corner pillars, beams, and cables have been assembled and fitted correctly.
  • Page 21 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. = 5033mm / 198.1 inches Check that all corner pillars are straight and level using a leveler.
  • Page 22 6. Assemble the LED strip lights READ AND FOLLOW ALL SAFETY INSTRUCTIONS • Do not cover this product as the covering may cause the flexible light to overheat and melt or ignite. • Do not operate with the flexible light tightly coiled. •...
  • Page 23 Place both LED light strips along the grooves on the side beams and end beams , as shown in the figure. Put the connection socket of the LED light strip close to the cabled corner pillar , and put the end of the LED light strip into the top of the corresponding corner pillar if needed.
  • Page 24 7. Connect the power cables of the LED strip lights 5 pin 5 pin Connect the cable connector (5-pin) of the cabled corner pillar to the cable connector (5-pin) of the control Connect the cable connector (4-pin) of the LED light strip to the corresponding connector socket of the cabled corner pillar...
  • Page 25 Carefully tuck all connected cables and connectors at the top of the structure back into the corner pillar. Attach and assemble the corner fittings with the screws...
  • Page 26 8. Assemble the roof deck sheets & and canopy Take a roof deck sheet (wide) place it at the right end of the structure, so that it makes contact with the cabled corner pillar . Please ensure the cable passes through the cutout at the end of the roof deck sheet (wide) Carefully fit the light control box into the roof deck sheet (wide)
  • Page 27 Take a roof deck sheet (narrow) place it next to the roof deck sheet (wide) so that it overlaps onto the roof deck sheet (wide) Secure the roof deck sheet with two screws and two pin washers each end of the deck sheet.
  • Page 28 Repeat steps , placing the roof deck sheets (wide) and roof deck sheets (narrow) alternately until the entire top of the structure is covered. Secure each sheet with two screws and two pin washers at each end of each sheet, except for the final roof deck sheet (wide) , which should be secured with one screw...
  • Page 29 Spread the canopy on top of the assembled sheets so that it covers the entire top of the structure. Align the holes of the canopy with the washers on each end of the sheets ( & Insert the screws through the holes of the canopy on each end of the roof deck sheets (...
  • Page 30 9. Finalize the electric connection and assemble the pillar cover Connect the cable on the base of the cabled corner pillar to the cable of the power supply adapter Tighten firmly. Tip: It is recommended to wrap waterproof adhesive tape on the waterproof connectors to prolong their service life.
  • Page 31 10. Secure the corner pillars to the ground The gazebo must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your gazebo”. To fix the corner pillars ( &...
  • Page 32 12. End of assembly...

  • Page 33: Assembly 6 Pillar

    ASSEMBLY 6-pillar Assembly Video...
  • Page 34 1. Set up the corner pillars Fix the cable flange with screws onto the cabled corner pillar , and make sure the cable is hanging outside. Slide the foot plate cover with its wide opening facing outwards on the straight end of the cabled corner pillar...
  • Page 35 Push the foot plate against the straight end of the cabled corner pillar . It only fits in one direction and in one position. If in doubt, rotate it until it fits easily. Screw in the foot plate with 6 screws using a cordless screwdriver.
  • Page 36 2. Connect the side beams ( & ) to the cabled corner pillar and a standard corner pillar Using a hex key (large) , slightly loosen the 4 built-in screws at the ends of side beam and side beam Take two connector plates , and put one on top of the other, as shown in the diagram.
  • Page 37 Slide side beams into the connector plates until the ends of beams meet, making sure they are aligned with the screw holes and sockets. Screw in and tighten the built-in screws using the hex key Align the newly connected side beams with the corresponding pillars...
  • Page 38 Slide the side beam into the grooves of the cabled corner pillar in such a way that the slot nuts of the side beam interlock with the slots in the cabled corner pillar Warning: Pull the cables out of the cabled corner pillar.
  • Page 39 3. Connect the remaining side beams to the remaining two standard corner pillars , and the remaining middle pillar Repeat steps to connect the remaining side beams with the remaining two corner pillars the remaining middle pillar...
  • Page 40 4. Slide in the two end beams This phase requires six persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 6 PEOPLE REQUIRED Only use ladders suitable for this kind of installation work. Stand the two structures built during steps 2 and 3 in an upright position, and place them at one end beam length...
  • Page 41 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the ratchet hex wrench provided. Assemble the other end beam repeating steps...
  • Page 42 5. Check the alignment of the frame and the distance between the corner pillars You are now almost done assembling the main frame of the gazebo. Please double check to ensure all corner pillars, beams, and cables have been assembled and fitted correctly.
  • Page 43 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. c = 4403mm / 173.3 inches d = 6635mm / 261.2 inches Check that all corner pillars are straight and level using a leveler.
  • Page 44 6. Assemble the LED strip lights READ AND FOLLOW ALL SAFETY INSTRUCTIONS • Do not cover this product as the covering may cause the flexible light to overheat and melt or ignite. • Do not operate with the flexible light tightly coiled. •...
  • Page 45 Place both LED light strips along the grooves on the side beams and end beams , as shown in the figure. Put the connection socket of the LED light strip close to the cabled corner pillar , and put the tail of the LED light strip into the top of the corresponding corner pillar if needed.
  • Page 46 7. Connect the power cables of the LED strip lights 5 pin 5 pin Connect the cable connector (5-pin) of the cabled corner pillar to the cable connector (5-pin) of the control Connect the cable connector (4-pin) of the LED light strip to the corresponding connector socket of the cabled corner pillar...
  • Page 47 Carefully tuck all connected cables and connectors at the top of the structure back into the corner pillar. Attach and assemble the corner fittings with the screws...
  • Page 48 Attach and assemble the middle fittings with the screws...
  • Page 49 8. Assemble the roof deck sheets & and canopy Take a roof deck sheet (wide) place it at the right end of the structure, so that it makes contact with the cabled corner pillar . Please ensure the cable passes through the cutout at the end of the roof deck sheet (wide) Carefully fit the light control box into the roof deck sheet (wide)
  • Page 50 Take a roof deck sheet (narrow) place it next to the roof deck sheet (wide) so that it overlaps onto the roof deck sheet (wide) Secure the roof deck sheet with two screws and two pin washers each end of the deck sheet.
  • Page 51 Repeat steps , placing the roof deck sheets (wide) and roof deck sheets (narrow) alternately until the entire top of the structure is covered. Secure each sheet with two screws and two pin washers at each end of each sheet, except for the final roof deck sheet (wide) , which should be secured with one screw...
  • Page 52 To assemble the middle pillar covers, fix a middle pillar cover to the top of each middle pillar with two screws each. Fix them using a cordless screwdriver. Spread the canopy on top of the assembled sheets so that it covers the entire top of the structure.
  • Page 53 Insert the screws through the holes of the canopy on each eand of the roof deck sheets ( & x 76 Check that all screws are firmly fixed on the canopy , as shown in the opposite figure.
  • Page 54 9. Finalize the electric connection and assemble the pillar cover Connect the cable on the base of the cabled corner pillar to the cable of the power supply adapter . Tighten firmly. Tip: It is recommended to wrap waterproof adhesive tape on the waterproof connectors to prolong their service life.
  • Page 55 10. Secure the corner pillars to the ground The gazebo must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your gazebo”. To fix the pillars , and with the foot plates...
  • Page 56 11. End of assembly...

  • Page 57: Operating Your Gazebo

    OPERATING YOUR GAZEBO Plug the power supply adapter into the mains The LED light will light up for two seconds and then turn off to indicate that the device has successfully powered on. If no light is observed, please make sure you have correctly followed all the connection instructions outlined in the assembly steps &...
  • Page 58 Button/Light Function Three favorite light modes can be stored. To store Store favorite 1 your favorite light mode, press and hold the star button When the left light starts flashing, Store favorite 2 press buttons to save your favorite light settings. The settings will be saved successfully after releasing the button.

  • Page 59: Problem Solving, Care & Maintenance

    PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take The LED light strip is deformed after removing it from the Expand the light strip and leave it at room temperature for a period of time until packaging. its shape is restored before installing it. The surface of the LED light strip oxidizes and changes color Regularly clean the surface to ensure cleanliness.
  • Page 60 GENERAL CARE & MAINTENANCE In most situations it should not be necessary to lubricate For more soiled areas, Dust and dirt will collect Use a water/detergent the moving components of Air dry or wipe with a soft rinse the surface with on the gazebo and will mixture and a soft clean the gazebo.

  • Page 61: Warranty & Complaints Procedure

    COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.

  • Page 62: Disassembly & Disposal Of The Product

    DISASSEMBLY & DISPOSAL OF THE PRODUCT When the service life of the gazebo is over, it is necessary to disassemble it for disposal and to sort the individual materials and components in compliance with the local regulations of your country. Incorrect disassembly of the gazebo may lead to serious injury and product damage.

  • Page 63: Certification Information

    ETL is a Certification Program provided by Intertek, which is a Recognized Testing Laboratory (NRTL) in the United States, and is accredited by institutes and associations such as ANSI, A2LA, and UKAS. The Mirador 111 Gazebo LED is ETL certified in the United States of America under Control Number 5026666 5026666...
  • Page 64 Unique Identifier Product Description Mirador Pergola Model Number 111 Gazebo LED A / 111 Gazebo LED S Trade Name Mirador FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 65 FOLLOW US ON WWW.MIRADOROUTDOOR.COM @miradoroutdoor @MiradorOutdoor @miradoroutdoor @miraadoroutdoor...
