THANK YOU FOR PURCHASING OUR MIRADOR BIOCLIMATIC PERGOLA! This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.
TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - List of Parts - Installation - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly and Disposal of the Product - Certification Information...
BEFORE ASSEMBLING YOUR PERGOLA Please read all the instructions carefully before you begin, and follow the steps in the order they are presented. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
Page 5
Check to ensure there are no missing parts: Before you begin installation, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please refer Warranty &...
IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the pergola, it is important to follow the safety guidelines below. If using power tools or The pergola must be Always wear appropriate Work well away from power Make sure the pergola a ladder, always follow positioned and fixed on flat...
Page 7
Installation of non-Mirador Put the louvers into the After prolonged use we branded accessories will void Do not attempt to assemble vertical position during recommend you check all Please recycle packaging the product warranty and the product if you are tired, or...
LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. Length PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen Width installation location. Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA.
Page 9
Part Name 2.4m/8ft. 3m/10ft. 3.6m/12ft. Part Name 2.4m/8ft. 3m/10ft. 3.6m/12ft. Foot plate Screw 4 pcs 4 pcs 4 pcs 56+3 pcs 72+4 pcs 88+4 pcs cover ST4.8x16mm Foot plate 4 pcs 4 pcs 4 pcs Cotter pin 6+2 pcs 6+2 pcs 6+2 pcs Louver end 1 pcs...
INSTALLATION 1. Set up the corner pillars Installation Video Slide the foot plate cover with its wide opening facing outwards on the straight end of the corner pillar Insert the foot plate into the straight end of the corner pillar and secure it with 8 screws using a cordless...
Page 11
2. Connect the side beam with gearbox to the corner pillars Lay two corner pillars and place the side beam with gearbox on the floor, as shown in the picture. Slide the side beam with gearbox into the grooves of the corner pillars , in such a way that the slot nuts of the side beam interlock with those of the corner pillars.
Page 12
Secure the side beam with 2 screws on the upper side by using hex key and 2 screws on the bottom side by using hex key S6...
Page 13
3. Connect the side beam without gearbox to the remaining two regular corner pillars Repeat steps to connect the side beam without gearbox with the remaining two corner pillars 4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling.
Page 14
Slide the slot nuts of the end beams from above into the slots of the corner pillars Secure the end beam with 2 screws on the upper side by using hex key and 2 screws on the bottom side by using hex key S6...
Page 15
Install the other end beam following steps...
Page 16
5. Check the alignment of the frame and the distance between the corner pillars You are now almost done installing the main frame of the pergola. Please double check to ensure all beams and pillars have been installed and fitted correctly. You may have to unscrew certain bolts during this step.
Page 17
Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. Size (m/ft) (mm) (inch) 3x2.4/10x8 3592 141.4 3x3/10x10 3997...
Page 18
6. Install Crank Locate the gearbox on the side beam with gearbox Gearbox Unscrew and remove the small screw from the crank connector. Insert the crank coupler into the crank connector and re-insert and tighten the small screw.
Page 19
Insert the end of the crank into the crank coupler , and turn until the crank locks firmly in place.
Page 20
7. Install louvers Prepare the driving louver Attach the louver end cap with control to right end of the driving louver Use 2 screws to fix them firmly, using a cordless screwdriver. Attach an louver end cap to the other end of the driving louver and use 2 screws to fix them firmly, using a cordless screwdriver.
Page 21
Insert connecting fixed axis louver shaft into the louver end cap with driving arm and secure them with 2 cotter pin Insert connecting fixed axis louver shaft into the louver end on the other side of the driving louver and secure them with 2 cotter pin...
Page 22
Prepare regular louvers Attach the Louver end cap / louver end cap to the right/left end of the louver . Use 2 screws on each side ,and fix them firmly using a cordless screwdriver. Part \ Length 2.4m/8ft. 3m/10ft. 3.6m/12ft.
Page 23
Place the shaft seat at the 2nd position from the right on both sides of the beams ( & Loosen the screw and washer already attached to the beam . Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key...
Page 24
Secure the driving louver in the shaft support brackets by fixing a shaft support cover onto the shaft seat both ends. Use two screws each and secure them with a cordless screwdriver.
Page 25
Place the shaft seat on both sides of the beams ( & ) , and place the remaining louvers into the remaining shaft seats Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft seats both ends.
Page 26
Take the connecting strip . Attach it to each louver, fitting each of the holes onto the corresponding shaft of the louvers. To fix driving louver , insert and secure a cotter pin through the small shaft hole on the driving louver. Use 1 screw to fix each louver with firmly.
Page 27
8. Secure the corner pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the corner pillars with the four foot plates , drill through each hole with a hammer...
OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle counter clockwise.
PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take Check if any of the louvers are deformed. If this is the case, replace them. If the Abnormal noise occurs during the rotation of the louver(s). louvers are not deformed but they are colliding with one another, replace the beam.
Page 31
GENERAL CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture For more soiled areas, rinse the Air dry or wipe with a soft clean pergola and will require periodic and a soft clean cloth to clean surface with clean water from top cloth.
COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.
DISASSEMBLY AND DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling.
INFORMATION Declaration of performance (DOP) Reference no. DOP0002 Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 80 Solid AxBm, 80 AxBm, AxB: 3x2, 3x2.4, 3x3, 3x4, 3x5 ,3x6...
