Summary of Contents for MIRADOR SHUTTER WALL

  • Page 2 IMPORTANT Please read the entire manual carefully before installing and using your shutter wall, and please ensure the manual is kept in a safe place for future reference. Any use or modification to the shutter wall not included in this manual shall be considered as improper use, which may cause considerable danger to users and property and will void the product warranty.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Shutter Wall - Important Safety Advice - List of Parts - Installation - Care & Maintenance - Warranty & Complaints Procedure...

  • Page 4: Before Assembling Your Shutter Wall

    Make sure you have all the tools required for assembling your shutter wall In order to assemble your shutter wall safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Most terraces or patios are designed with a slight slope to prevent (rain) water from forming pools or reaching the house or other structures. For the perfect shutter wall installation, a level surface without such a slope is required. Small pebbles could also prevent the shutter wall from being safely secured on the ground.

  • Page 6: Important Safety Advice

    IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the shutter wall, it is important to follow the safety guidelines below. The shutter wall must be positioned and fixed on flat level surface. Hot items such as recently Do not attempt to assemble used grills, blowtorches etc.
  • Page 7 Keep clothing and body parts Electrical Installation may only be away from the shutter wall to carried out by certified personnel prevent them from getting according to the applicable caught in the moving parts regulation(e.g.

  • Page 8: List Of Parts

    LIST OF PARTS Part name Part name Screw Right Vertical Beam 1 pcs 2 pcs ST4.8x25mm Screw Left Vertical Beam 1 pcs 11 pcs ST4.8x30mm Louver 28 pcs Horizontal Top Bar 1 pcs Foot Pad 2 pcs Horizontal Bottom Bar 1 pcs Screw 4 pcs...

  • Page 9: Installation

    INSTALLATION Installation video 1.VERTICAL & HORIZONTAL BEAM ASSEMBLY Insert all of the louvers C into the left vertical beam B. Ensure the inside hole is located at the bottom. x 28 Place the right vertical beam A onto the louvers, ensure the inside hole is located at the bottom.
  • Page 10 Insert the horizontal top bar J & horizontal bottom bar K to the top and bottom sides of the assembled frame. Notice: -Pay attention to the direction of J while assembled to A . - K is Near the hole at the bottom of the vertical side beams Secure the vertical beams to the louvers using the Screw ST4.8x30mm I...
  • Page 11 Notice: There is no need to install foot pad D on the side near the pergola pillar. Below parts are needed for 3 different installation positions of the shutter wall. Left or Right hand side wall Center hand side wall...
  • Page 12 F with hammer. (left/right hand side) (center) Notice：Always start from the left/right hand side shutter wall if it is intended to install more than 1 shutter wall on one side of the pergola.
  • Page 13 Hook the shutter wall onto the beam of the pergola, secure the wall with screw ST4.8x25mm Using screwdriver. Using screwdriver. Fix the shutter wall to the ground with Screw ST5.5x50mm E. . (left/right hand side) (center) Fix the left/right hand side shutter wall to pergola pillar with Screw ST4.8x38mm G.
  • Page 14 4.END OF INSTALLATION Purchase 3 individual shutter walls to enclose one side. Pay attention to the length of the attented size(10' or 13') and match them accordingly.

  • Page 15: Care & Maintenance

    In coastal areas, it is recommended that For more soiled areas, rinse the you frequently spray the shutter wall Do not use any petroleum based surface with clean water from top spray lubricant. with water to reduceaccumulation to bottom.

  • Page 16: Warranty & Complaints Procedure

    WARRANTY & COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com . Complaints procedure: The complaint must include an order number or transaction number . • The complaint must include a detailed description of the defect, the name of the company which installed the product and the date •...
