THANK YOU FOR PURCHASING OUR MIRADOR 111 LED PERGOLA! THIS INSTRUCTION MANUAL IS FOR THE FOLLOWING MODELS: Single steel Double aluminum Louver Model name 111 S LED 111 DA LED This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.
TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - Technical Data - List of Parts - Assembly - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly & Disposal of the Product - Certification Information...
BEFORE ASSEMBLING YOUR PERGOLA WARNING: Improtant safety instructions. Follow all instructions, since incorrect assembly can lead to severe injury. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
Page 5
Check to ensure there are no missing parts: Before you begin assembly, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please refer Warranty &...
Approved Electrical installation may only Mirador 111 LED pergolas Put the louvers into the Make sure all electrical be carried out by certified should only be connected...
Page 7
Installation of non-Mirador Do not start the roof After prolonged use we branded accessories will void mechanism in case of frost Do not attempt to assemble recommend you check all the product warranty and Do not climb on the roof.
Page 8
WARNING: When using outdoor use portable lighting products, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following: WARNING WARNING WARNING WARNING Use only outdoor extension Material may become brittle Do not mount or support Risk of Fire and Electric cords, such as type SW, SOW,...
TECHNICAL DATA Resistance to wind loads Class 6 ( Claimed Beaufort Wind Force Scale 12 ) Pergola Resistance to water pocket Class 1 Mechanical endurance Class 1 Ingress Protection Rating IP54 Control Box Input Voltage 24V DC Output Voltage 24V DC Input Voltage 24V DC Light LED Strip...
LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. Length PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Width Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA.
Page 11
Part Part 3m/10ft. 3.6m/12ft. 4m/13ft. 3m/10ft. 3.6m/12ft. 4m/13ft. Name Name Foot plate Hex key cover (small) Hex key Foot plate (large) Shaft 12mm SDS support 38+2 46+2 50+2 Plus Drill cover Corner Power pillar cover supply Corner LED light pillar cover strip (logo) Screw...
Page 12
LOUVER RELATED VARIATIONS The type of louver provided depends on the model of pergola you have purchased: Model 111 DA LED 111 S LED Louver type Double aluminum Single steel Double aluminum Part Name 3m/10ft. 3.6m/12ft. 4m/13ft. Louver Louver end cap 37+2 45+2 49+1...
ASSEMBLY 1. Set up the corner pillars Assembly Video Fix the cable flange with screws onto the cabled corner pillar , and make sure the cable is hanging outside. Slide the foot plate cover with its wide opening facing outwards on the straight end of the corner pillar...
Page 14
Push the foot plate against the straight end of the cabled corner pillar . It only fits in one direction and in one position. If in doubt, rotate it until it fits easily. Screw in the foot plate with 6 screws using a cordless screwdriver.
Page 15
2. Connect the side beam with gearbox to the corner pillars Pull out the cable at the end of the with gearbox through the small cut-out. Using a hex key (large) , slightly loosen the 8 built-in screws at the both ends of the with gearbox (4 on each side).
Page 16
Lay two corner pillars ( & ) and place the side beam with gearbox on the floor as shown in the picture. Side beam with gearbox into the grooves of the corner pillar ( & in such a way that the slot nuts of the side beam with gearbox interlock with the slots in the corner pillar (...
Page 17
Tighten the 8 screws ( 4 on each side) with the hex key 3. Connect the side beam without gearbox to the remaining two regular corner pillars Repeat steps to connect the beam without gearbox with the remaining two corner pillars...
Page 18
4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 4 PEOPLE REQUIRED Only use ladders suitable for this kind of assembly work. Gearbox Stand the two structures built during steps 2 and 3 in an upright position,...
Page 19
Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the hex key provided. Assemble the other end beam repeating steps...
Page 20
5. Install the LED strip lights READ AND FOLLOW ALL SAFETY INSTRUCTIONS • Do not cover this product as the covering may cause the flexible light to overheat and melt or ignite. • Do not operate with the flexible light tightly coiled. •...
Page 21
Place both LED light strips along the grooves on the side beams ( & and end beams , as shown in the figure. Put the connection socket of the LED light strip close to the cabled corner pillar , and put the end of the LED light strip into the top of the corresponding corner pillar if needed.
Page 22
6. Connect the power cables of the LED strip lights 5 pin 5 pin Connect the cable connector (5-pin) of the side beam with gearbox into the corresponding connector socket on the top of the cabled corner pillar . Then tighten the waterproof connector.
Page 23
Carefully tuck all connected cables and connectors at the top of the structure back into the corner pillar. 7. Check the alignment of the frame and the distance between the corner pillars You are now almost done assembling the main frame of the pergola. Please double check to ensure all beams and pillars have been assembled and fitted correctly.
Page 24
Measure the distances between the adjacent corner pillars. Adjust accordingly and ensure the distances match those shown in the opposite figure. Size (m/ft) (mm) (inch) (mm) (inch) 3x3/10x10 2790.5 109.9 2790.4 109.9 3x3.6/10x12 2790.5 109.9 3400 133.9 3x4/10x13 2790.5 109.9 3705 145.9 3.6x3.6/12x12...
Page 25
Check that all corner pillars are straight and level using a leveler. If the corner pillars or beams are still not level, this means that your main building surface isn’t sufficiently level, and that you will need to raise the corner pillars that are positioned lower than the others.
Page 26
8. Assemble Crank Gearbox Locate the gearbox on the side beam with gearbox Unscrew and remove the small screw from the crank connector. Insert the crank coupler into the crank connector and re-insert and tighten the small screw.
Page 27
Insert the end of the crank into the crank coupler , and turn until the crank locks firmly in place.
Page 28
9. Assemble Louvers Double aluminum Single steel Double aluminum Prepare the driving louver: select one of the louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver.
Page 29
Single steel Double aluminum Prepare the regular louvers: attach the louver end caps to each end of the rest of the louvers with two screws using a cordless screwdriver. Repeat this step for all louvers. Single steel Part \ Length 3m/10ft.
Page 30
Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
Page 31
Place the rest of the louvers into the remaining shaft support brackets. Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft support brackets on both ends of each louver . Use two screws each and secure them with a cordless screwdriver.
Page 32
Take the connecting strip . Attach it to each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. Repeat this step for all cotter pins.
Page 33
10. Finalize the electric connection and assemble the pillar cover Assemble the antenna on the side beam 2 pin 2 pin Connect the cable on the base of the cabled corner pillar to the cable of the power supply adapter Tighten firmly.
Page 34
Fix a pillar cover to the top of each corner with three screws each . Fix them using a cordless screwdriver. N/N2 x 12...
Page 35
11. Secure the corner pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the corner pillars ( &...
OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle counter clockwise.
Page 38
LIGHT STRIP REMOTE CONTROL GUIDE Plug the power supply adapter into the mains The LED light will light up for two seconds and then turn off to indicate that the device has successfully powered on. If no light is observed, please make sure you have correctly followed all the connection instructions outlined in the assembly steps &...
Page 39
Button/Light Function Store favorite 1 Three favorite light modes can be stored. To store your favorite light mode, press and hold the star button .When the left light starts flashing, press buttons Store favorite 2 to save your favorite light settings. The settings will be saved successfully after releasing the button.
PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take The LED light strip is deformed after removing it from the Expand the light strip and leave it at room temperature for a period of time packaging. until its shape is restored before installing it. The surface of the LED light strip oxidizes and changes color after Regularly clean the surface to ensure cleanliness.
Page 41
GENERAL CARE & MAINTENANCE The drive shall be Dust and dirt will collect Use a water/detergent Disconnect the cables if disconnected from its Air dry or wipe with a soft on the pergola and will mixture and a soft clean the pergola is not being power source during clean cloth.
COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.
DISASSEMBLY & DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling. Disposal of used Electrical and Electronic Equipment When the service life of the product is over, it is necessary to disassemble it for disposal and to sort the individual materials and components in compliance with the local regulations of your country.
ETL is a Certification Program provided by Intertek, which is a Recognized Testing Laboratory (NRTL) in the United States, and is accredited by institutes and associations such as ANSI, A2LA, and UKAS. The Mirador 111 LED Series is ETL certified in the United States of America under Control Number 5026666 5026666...
Page 45
Unique Identifier Product Description Mirador Pergola Model Number 111 LED DA / 111 LED S Trade Name Mirador FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 46
3x5.3, 3x6, 3x7.2, 3.6x5.3, 3.6x6, 3.6x7.2 111 Classic AxBm, 111 Classic e AxBm, 111 Classic e-Motion AxBm, 111 S AxBm, 111 LED S AxBm, 111 e-Motion S AxBm, 111 Premium AxBm, 111 Premium e AxBm, 111 Premium e-Motion AxBm, 111 A AxBm, 111 LED A AxBm, 111 e-Motion A AxBm, AxB: 3x3, 3x3.6, 3x4,...
Page 47
