Summary of Contents for MIRADOR 111 Pergola e-Motion

  • Page 1 111 PERGOLA E-MOTION +...
  • Page 2 This pergola is intended for outdoor domestic use in residential environments, and to protect users from direct sunlight, glare and heat . Any use and property and will void the product warranty. E-Mail: info@miradoroutdoor.de 111 PERGOLA E-MOTION+ 4 PILLARS EN 23v2.1...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - Technical Data - List of Parts - Installation - Operation of Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly and Disposal of the Product...

  • Page 4: Before Assembling Your Pergola

    BEFORE ASSEMBLING YOUR PERGOLA WARNING: Improtant safety instructions. Follow all instructions, since incorrect installation can lead to severe injury. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Check to ensure there are no missing parts: Before you begin installation, please check that you have all the parts required to assemble your e-Motion. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please refer Warranty &...

  • Page 6: Important Safety Advice

    IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the pergola, it is important to follow the safety guidelines below. Always wear appropriate work shoes, Work well away from power lines, If using power tools or a ladder, The pergola must be positioned and gloves and eye protection when particularly when handling metal...
  • Page 7 Hazardous unprotected moving parts Keep clothing and body parts away Foliage or other foreign objects on Put the louvers into the vertical of the drive shall be installed higher from the pergola to prevent them the louvers and in the guide rails position during snowfall or wind to from getting caught in the moving should be removed regularly, to...
  • Page 8 Changes to the design or Prior to each operation, visually check If the supply cord is damaged, it must configuration of equipment may Hot items such as recently used the pergola for damage. If damage is be replaced by the manufacturer, its not be made without consulting grills, fire pits etc.

  • Page 9: Technical Data

    TECHNICAL DATA Continuous Operating Cycle 10 cycles Sound Pressure Level ≤70 dB Pergola Ingress Protection Rating IPX5 Wind Resistance Class 6 ( Claimed Beaufort Wind Force Scale 12 ) Input Voltage 24V DC Linear Actuator Ingress Protection Rating IP66 Input Voltage 24V DC Control Box Output Voltage...

  • Page 10: List Of Parts

    LIST OF PARTS PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA. USE A STANDARD CORDLESS SCREW DRIVER ON THE BASE SETTING. ALL HOLES HAVE BEEN PREDRILLED OR FITTED FOR ASSEMBLY.
  • Page 11 Part name 3m/10ft. 3.6m/12ft. 4m/13ft. Part name 3m/10ft. 3.6m/12ft. 4m/13ft. Foot Anchor plate bolt cover M8x80mm Foot Hex key plate (small) Louver Hex key 37+2 45+2 49+1 end cap (large) Louver end cap 12mm SDS with Plus Drill control Shaft Power support 38+2...

  • Page 12: Installation

    INSTALLATION 1. Set up the corner pillars Installation Video Fix the cable flange with screws onto the cabled corner pillar , and make sure the cable is hanging outside. Slide the foot plate cover with its wide opening facing outwards on the straight end of the cabled corner pillar...
  • Page 13 Push the foot plate against the straight end of the cabled corner pillar . It only fits in one direction and in one position. If in doubt, rotate it until it fits easily. Screw in the foot plate with 6 screws using a cordless screwdriver.
  • Page 14 2. Connect the side beam with motor to the cabled corner pillar and a regular corner pillar Pull out the cable at the end of the side beam with motor through the small cut-out. Using a hex key (large) , slightly loosen the 8 built-in screws at the both ends of the side beam with motor (4 on each side).
  • Page 15 Lay two corner pillars ( & ) and place the side beam with motor the floor as shown in the picture. Side beam with motor into the grooves of the corner pillars & ) in such a way that the slot nuts of the side beam with motor interlock with the slots in the corner pillars (...
  • Page 16 Tighten the 8 screws ( 4 on each side) with the hex key 3. Connect the side beam without motor to the remaining two regular corner pillars Repeat steps to connect the beam without motor with the remaining two corner pillars...
  • Page 17 4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. Only use ladders suitable for this kind of installation work. 4 PEOPLE REQUIRED Stand the two structures built during steps 2 and 3 in an upright position, and place them at one end beam...
  • Page 18 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the hex key provided. Install the other end beam repeating steps...
  • Page 19 5. Install the LED strip lights Place both LED light strips along the grooves on the side beams & ) and end beams , as shown in the figure. Put the connection socket of the LED light strip close to the cabled corner pillar , and put the end of the LED light strip...
  • Page 20 6. Connect the power cables of the motor and LED strip lights 5 pin 5 pin Connect the cable connector (5-pin) of the side beam with motor into the corresponding connector socket on the top of the cabled corner pillar .
  • Page 21 Carefully tuck all connected cables and connectors at the top of the structure back into the corner pillar. 7. Check the alignment of the frame and the distance between the corner pillars You are now almost done installing the main frame of the pergola. Please double check to ensure all corner pillars, beams, and cables have been installed and fitted correctly.
  • Page 22 Measure the distances between the adjacent corner pillars. Adjust accordingly and ensure the distances match those shown in the opposite figure. Size (m/ft) (mm) (inch) (mm) (inch) 3x3/10x10 2790.5 109.9 2790.4 109.9 3x3.6/10x12 2790.5 109.9 3400 133.9 3x4/10x13 2790.5 109.9 3705 145.9 3.6x3.6/12x12...
  • Page 23 Check that all corner pillars are straight and level using a spirit level. If the corner pillars or beams are still not level, this means that your main building surface isn’t sufficiently level, and that you will need to raise the corner pillars that are positioned lower than the others.
  • Page 24 8. Install the louvers, and connecting strip Prepare the driving louver: select one of the louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver.
  • Page 25 Prepare the regular louvers: attach the louver end caps to each end of the rest of the louvers with two screws using a cordless screwdriver. Repeat this step for all louvers. Part \ Length 3m/10ft. 3.6m/12ft. 4m/13ft. Place the louvers on the corresponding louver shaft support on both side beams (...
  • Page 26 Loosen the screw and washer already attached to the beam with motor. Then fix the connecting rod of the driving louver to the side beam with motor by firmly tightening the same screw and washer, using the hexagon socket key Place the rest of the louvers into the remaining shaft support brackets.
  • Page 27 Part \ Length 3m/10ft. 3.6m/12ft. 4m/13ft. Take the connecting strip . Attach it to each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter , inserting it through the small bolt hole.Repeat this step for all cotter pins.
  • Page 28 9. Finalize the electric connection and install the pillar cover Install the 2.4G and 4G antenna and make sure they correspond to the label on the side beam with motor To install the pillar cover, fix a pillar cover to the top of each corner with three screws each .
  • Page 29 2 pin 2 pin Connect the cable on the base of the cabled corner pillar to the cable of the power supply adapter . Tighten firmly. Tip: It is recommended to wrap waterproof adhesive tape on the waterproof connectors to prolong their service life. 10.
  • Page 30 Plug the power supply adapter into the mains. Warning: To reduce the risk of electric shock, this equipment has a polarized plug (one blade is wider than the other). This plug outlet only one way. the proper outlet. Do not change the plug in any way.
  • Page 31 11. Secure the corner pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the corner pillars ( &...

  • Page 32: End Of Installation

    12. End of installation...

  • Page 33: Operation Of Your Pergola

    Store by scanning the QR code below If you have problem paring or controlling the pergola II. Open the Mirador app and scan the QR code on the • Stand closer to the pergola nameplate on the beam to pair the pergola •...

  • Page 34: Problem Solving, Care & Maintenance

    PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take The LED light strip is deformed after removing it from the Expand the light strip and leave it at room temperature for a period of packaging. time until its shape is restored before installing it. The surface of the LED light strip oxidizes and changes color Regularly clean the surface to ensure cleanliness.

  • Page 35: General Care And Maintenance

    Issue Explanation or action to take Some of the light beads on the LED light strip do not work Replace the light strip. according to the instructions. The flatness of the louver is damaged due to weather Replace the affected louvers. conditions.

  • Page 36: Periodic Inspection

    In most situations it is not necessary Disconnect the awning from the For more soiled areas, rinse the to lubricate the moving parts of the Do not use any petroleum based supply when maintenance, such as surface with clean water from top to pergola.

  • Page 37: Warranty & Complaints Procedure

    WARRANTY & COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.de or contact your local Pergola sales representative. Contact: Customer Service: info@miradoroutdoor.de...

  • Page 38: Disassembly And Disposal Of The Product

    DISASSEMBLY AND DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling.

  • Page 39: Certification Information

    CERTIFICATION INFORMATION - Declaration of performance (DOP) - EU Declaration of Conformity - EC Declaration of Conformity - UK Declaration of Conformity - ETL - FCC...

  • Page 40: Declaration Of Performance (Dop)

    Declaration of performance (DOP) Reference no. DOP0001 Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 111 Deluxe AxBm, 111 Deluxe e AxBm, 111 Deluxe e-Motion RC AxBm, 111 Deluxe e-Motion AxBm,...

  • Page 41: Eu Declaration Of Conformity

    EU Declaration of Conformity Product name Mirador Pergola Model name/ Unique identification code of the product: 111 Deluxe e-Motion RC 3x7.2m, 111 Deluxe e-Motion RC 3.6x3.6m, 111 Deluxe e-Motion RC 3.6x4m, 111 Deluxe e-Motion RC 3.6x5.3m, 111 Deluxe e-Motion RC 3.6x6m, 111 Deluxe e-Motion RC 3.6x7.2m 111 Deluxe e-Motion 3x3m, 111 Deluxe e-Motion 3x3.6m, 111 Deluxe e-Motion 3x4m, 111 Deluxe e-Motion 3x5.3m,...

  • Page 42: Ec Declaration Of Conformity

    EC Declaration of Conformity Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 111 Deluxe AxBm, 111 Deluxe e AxBm, 111 Deluxe e-Motion RC AxBm, 111 Deluxe e-Motion AxBm...

  • Page 43: Declaration Of Conformity

    UK Declaration of Conformity Product name and type Mirador Pergola Model name/ Unique identification code of the product: 111 Deluxe AxBm, 111 Deluxe e AxBm, 111 Deluxe e-Motion RC AxBm, 111 Deluxe e-Motion AxBm 111 Deluxe Edge AxBm, 111 Deluxe Edge e AxBm, 111 Deluxe Edge e-Motion RC AxBm, 111 Deluxe Edge e-Motion AxBm...

  • Page 44: Etl

    ETL is a Certification Program provided by Intertek, which is a Recognized Testing Laboratory (NRTL) in the United States , and is accredited by institutes and associations such as ANSI, A2LA, and UKAS. The Mirador 111 DA e-Motion+ is ETL certified in the United States of America and Canada under Control Number 5026666...

  • Page 45: Fcc

    FCC INFORMATION Supplier's Declaration of Conformity Compliance Information Unique Identifier Product Description Mirador Pergola Model Number 111 e-Motion+ Trade Name Mirador FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 46 WWW.MIRADOROUTDOOR.DE...
