MIRADOR LIFE GRILL S1 Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EN
GRILL S1
INSTRUCTION MANUAL
LIFE SERIES
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIFE GRILL S1 and is the answer not in the manual?

Questions and answers

Related Manuals for MIRADOR LIFE GRILL S1

Summary of Contents for MIRADOR LIFE GRILL S1

  • Page 1 GRILL S1 INSTRUCTION MANUAL LIFE SERIES...
  • Page 2 THANK YOU FOR PURCHASING OUR MIRADOR GRILL S1 PERGOLA! This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - List of Parts - Assembly - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly & Disposal of the Product...

  • Page 4: Before Assembling Your Pergola

    BEFORE ASSEMBLING YOUR PERGOLA WARNING: Improtant safety instructions. Follow all instructions, since incorrect assembly can lead to severe injury. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Check to ensure there are no missing parts: Before you begin assembly, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased. If any parts are missing, please refer Warranty &...

  • Page 6: Important Safety Advice

    IMPORTANT SAFETY ADVICE For the safety of all persons assembling and using the pergola, it is important to follow the safety guidelines below. If using power tools or The pergola must be Always wear appropriate Work well away from power Make sure the pergola a ladder, always follow positioned and fixed on flat...
  • Page 7 Assembly of non-Mirador Put the louvers into the After prolonged use we branded accessories will void Do not exceed the weight vertical position during recommend you check all Please recycle packaging the product warranty and limit when using the bar shelf.

  • Page 8: List Of Parts

    LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. 3m/10ft. PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen 1.5m/5ft. installation location. Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA.
  • Page 9 Part Nwame Part Name Connecting strip 2 pcs Screw M5x12mm 76+4 pcs Crank 1 pcs Screw 4.2x25mm 76+4 pcs Foot plate cover 4 pcs Screw 5.5x19mm 44+2 pcs Foot plate 4 pcs Cotter pin 38+6 pcs Louver end cap 37+2 pcs Crank coupler 1 pcs Louver end cap...

  • Page 10: Assembly

    ASSEMBLY 1. Set up the corner pillars Assembly Video Slide the foot plate cover with its wide opening facing outwards on the straight end of the corner pillar & & Push the foot plate against the straight end of the corner pillar &...
  • Page 11 2. Connect the side beam with gearbox to the corner pillars Using a hex key (large) , slightly loosen the 8 built-in screws at both ends of the side beam with gearbox .(4 on each side) Lay corner pillar & and the side beam with gearbox down on the...
  • Page 12 Tighten the screw with the hex key 3. Connect the side beam without gearbox to the remaining two corner pillars Repeat steps to connect the beam without gearbox with the remaining two corner pillars.
  • Page 13 4. Slide in the two end beams This phase requires four persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 4 PEOPLE REQUIRED Only use ladders suitable for this kind of assembly work. Gearbox Stand the two structures built during steps 2 and 3 in an upright position, and...
  • Page 14 Slide the slot nuts of the end beams from above into the slots of the corner pillars & Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the hex key provided. Assemble the other end beam repeating steps...
  • Page 15 5. Check the alignment of the frame and the distance between the corner pillars You are now almost done assembling the main frame of the pergola. Please double check to ensure all beams and pillars have been assembled and fitted correctly. You may have to unscrew certain bolts during this step.
  • Page 16 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. = 309.5 cm / 121.8 inches Check that all corner pillars are straight and level using a leveler.
  • Page 17 6. Assemble crank Gearbox Locate the gearbox on the side beam with gearbox Unscrew and remove the small screw from the crank connector. Insert the crank coupler into the crank connector and re-insert and tighten the small screw.
  • Page 18 Insert the end of the crank into the crank coupler , and turn until the crank locks firmly in place.
  • Page 19 7. Assemble the louver & connecting strip Prepare the driving louver: select one of the louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver.
  • Page 20 Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
  • Page 21 Place the rest of the louvers into the remaining shaft support brackets. Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft support brackets on both ends of each louver . Use two screws each and secure them with a cordless screwdriver.
  • Page 22 Take the connecting strip . Attach it to each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. Repeat this step for all cotter pins on both sides.
  • Page 23 8. Secure the corner pillar covers Fix a pillar cover to the top N/N2 of each corner with three screws each . Fix them using a cordless screwdriver. N/N2 A3/A4 x 12...
  • Page 24 9. Assemble bar table & secure the pergola to the ground Align the mounting holes on the pillars and bar shelf and connect them with screws by using cordless screwdriver. Assemble the bar shelf on the other side by repeating step...
  • Page 25 The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the pillars with the four foot plates , drill through each hole with a hammer drill.
  • Page 26 Assemble the footrest on the other side by repeating step Tighten the hexagonal ends of each bolt with a spanner/wrench.
  • Page 27 10. End of assembly...

  • Page 28: Operating Your Pergola

    OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle counter clockwise.

  • Page 29: Problem Solving, Care & Maintenance

    PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take Check if any of the louvers are deformed. If this is the case, replace them. If the Abnormal noise occurs during the rotation of the louvers. louvers are not deformed but they are colliding with one another, replace the beam.
  • Page 30 GENERAL CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture For more soiled areas, rinse the Air dry or wipe with a soft clean pergola and will require periodic and a soft clean cloth to clean surface with clean water from top cloth.

  • Page 31: Warranty & Complaints Procedure

    COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.

  • Page 32: Disassembly & Disposal Of The Product

    DISASSEMBLY & DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling.
  • Page 33 FOLLOW US ON WWW.MIRADOROUTDOOR.COM @miradoroutdoor @MiradorOutdoor @miradoroutdoor @miraadoroutdoor...
