  • Page 2 THANK YOU FOR PURCHASING OUR MIRADOR BIOCLIMATIC PERGOLA! THIS INSTRUCTION MANUAL IS FOR THE FOLLOWING MODELS: Single aluminum Single Steel Double aluminum Series \ Louver 111 Premium 111 Classic 111 Deluxe 111 A 111 S 111 DA This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your pergola, to ensure it brings you many years of use and enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS - Before Assembling Your Pergola - Important Safety Advice - List of Parts - Installation - Operating Your Pergola - Problem Solving, Care & Maintenance - Warranty & Complaints Procedure - Disassembly and Disposal of the Product - Certification Information...

  • Page 4: Before Assembling Your Pergola

    BEFORE ASSEMBLING YOUR PERGOLA WARNING: Improtant safety instructions. Follow all instructions, since incorrect installation can lead to severe injury. Make sure you have all the tools required for assembling your pergola: In order to assemble your pergola safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided.
  • Page 5 Check to ensure there are no missing parts Check to ensure there are no missing parts: Before you begin installation, please check that you have all the parts required to assemble your pergola. Please also carefully check that the Before you begin installation, please check that you have all the parts required to assemble your pergola. Please also carefully check that the quantity of parts match with that of the model you have purchased.

  • Page 6: Important Safety Advice

    IMPORTANT SAFETY ADVICE For the safety of all persons installing and using the pergola, it is important to follow the safety guidelines below. If using power tools or The pergola must be Always wear appropriate Work well away from power Make sure the pergola a ladder, always follow positioned and fixed on flat...
  • Page 7 Installation of non-Mirador Put the louvers into the After prolonged use we branded accessories will void Do not attempt to assemble vertical position during recommend you check all Please recycle packaging the product warranty and the product if you are tired, or...

  • Page 8: List Of Parts

    LIST OF PARTS Please carefully check that the quantity of parts matches with that of the model you have purchased. Length PLEASE NOTE that the anchor bolts provided may not be suitable for your chosen installation location. Width Please check before proceeding. DO NOT USE AN IMPACT CORDLESS SCREW DRIVER TO ASSEMBLE THE PERGOLA.
  • Page 9 Part Name 5.3m/17ft. 6m/20ft. 7.2m/24ft. Foot plate cover 6 pcs 6 pcs 6 pcs Foot plate 6 pcs 6 pcs 6 pcs Shaft support cover 68+3 pcs 76+3 pcs 92+3 pcs Corner pillar cover 4 pcs 4 pcs 4 pcs Middle pillar cover 2 pcs 2 pcs...
  • Page 10 Part Name 5.3m/17ft. 6m/20ft. 7.2m/24ft. Hex key (small) 1 pcs 1 pcs 1 pcs Hex key (large) 2 pcs 2 pcs 2 pcs 12mm SDS Plus Drill Bit 1 pcs 1 pcs 1 pcs Spare plastic pin 0+10 pcs 0+10 pcs 0+10 pcs The type of louver provided depends on the model of pergola you have purchased:...
  • Page 11 Single aluminum Part Name 5.3m/17ft. 6m/20ft. 7.2m/24ft. Louver 34 pcs 38 pcs 46 pcs Louver end cap 66+3 pcs 74+3 pcs 90+3 pcs Louver end cap 2 pcs 2 pcs 2 pcs with control arm Connecting strip 4 pcs 4 pcs 4 pcs Cotter pin 68+10 pcs...

  • Page 12: Installation

    INSTALLATION 1. Set up the pillars & Installation Video Slide the foot plate cover with its wide opening facing outwards on the straight end of the pillar & A&A1 A&A1 Push the foot plate against the straight end of the pillar &...
  • Page 13 2. Connect the side beams & to the corner pillars Slide the end of side beam into the end of side beam , until the end piece is no longer visible.
  • Page 14 Connect the two side beams by inserting the spacer sleeves and socket screws Using a hex key (large) , slightly loosen the 8 built-in screws at the corner ends of the side beams (4 on each side). Then loosen the top 6 built-in screws where the side beams meet in the middle.
  • Page 15 Align the newly connected side beams with the corresponding pillars Slide the side beams into the grooves of the pillars in such a way that the slot nuts of the side beams interlock with the slots in the pillars.
  • Page 16 Tighten the screw with the hex key 3. Connect the side beams without gearbox & to the remaining pillars & Repeat steps to connect the beams without gearbox with the remaining pillars...
  • Page 17 4. Slide in the two end beams This phase requires six persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. 6 PEOPLE REQUIRED Only use ladders suitable for this kind of installation work. Gearbox Stand the two structures built during steps 2 and 3 in an upright position, and...
  • Page 18 Slide the slot nuts of the end beams from above into the slots of the corner pillars Once the beam is in the correct position, tighten the 8 built-in screws on both ends using the hex key provided. Install the other end beam repeating steps...
  • Page 19 5. Check the alignment of the frame and the distance between the corner pillars You are now almost done installing the main frame of the pergola. Please double check to ensure all beams and pillars have been installed and fitted correctly. You may have to unscrew certain bolts during this step.
  • Page 20 Measure the diagonal distance between the opposite corner pillars. Adjust the other corner pillars accordingly until both diagonal distances are equal. You may have to repeat the above steps after completing the remaining steps. Size (m/ft) (mm) (inch) (mm) (inch) 3x5.3/10x17 3739 147.2...
  • Page 21 6. Install Cranks Gearbox Locate the gearboxes on the side beam with gearbox B & B1 Unscrew and remove the small screw from the crank connectors. Insert the crank couplers into the crank connectors and re-insert and tighten the small screw.
  • Page 22 Insert the end of the cranks into the crank couplers , and turn until the crank locks firmly in place.
  • Page 23 7. Install the louvers, and connecting strips Double aluminum Single aluminum Single Steel Double aluminum Prepare two driving louvers: select two louvers to be the driving louver. Attach the louver end cap with control to one end of the driving louver, and attach an louver end cap to the other end of the driving louver.
  • Page 24 Single Steel Double aluminum Prepare the regular louvers: attach the louver end caps to each end of the rest of the louvers with two screws using a cordless screwdriver. Repeat this step for all louvers. Single aluminum Single Steel Part \ Length 5.3m/17ft.
  • Page 25 Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
  • Page 26 Loosen the screw and washer already attached to the beam. Then fix the connecting rod of the driving louver to the side beam with gearbox , by firmly tightening the same screw and washer, using the hexagon socket key Place the louvers on the corresponding louver shaft support on both side beams (...
  • Page 27 Place two louvers on the shaft support , and brackets of the middle pillars attach the connecting rods as in step...
  • Page 28 Place the rest of the louvers into the remaining shaft support brackets. Secure the louvers in the shaft support brackets by fixing a shaft support cover onto the shaft support brackets on both ends of each louver . Use two screws each and secure them with a cordless screwdriver.
  • Page 29 Take the connecting strip . Attach it to each louver fitting each of the holes onto the corresponding bolts of the louvers. Secure every bolt with a cotter pin inserting it through the small bolt hole. Repeat this step for all cotter pins.
  • Page 30 8. Secure the corner pillar covers & middle pillar covers Fix a pillar cover to the top of each corner pillar with three screws each. Fix them using a cordless screwdriver. To install the middle pillar covers, fix a middle pillar cover to the top of each middle pillar with 2 screws...
  • Page 31 9. Secure the pillars to the ground The pergola must be firmly and permanently secured to the ground. If the ground is not level or suitable, please refer to the section “Before assembling your pergola”. To fix the pillars with the six foot plates , drill through each hole with a hammer drill.
  • Page 32 10. End of installation...

  • Page 33: Operating Your Pergola

    OPERATING YOUR PERGOLA When opening/closing the louvers, please ensure the crank remains in a vertical position next to the pillar. Do not move the crank too far away from the pillar. To open the louvers, turn the crank handle clockwise; To close the louvers, turn the crank handle counter clockwise.

  • Page 34: Problem Solving, Care & Maintenance

    PROBLEM SOLVING, CARE & MAINTENANCE Issue Explanation or action to take Check if any of the louvers are deformed. If this is the case, replace them. If the Abnormal noise occurs during the rotation of the louver(s). louvers are not deformed but they are colliding with one another, replace the beam.
  • Page 35 GENERAL CARE & MAINTENANCE Dust and dirt will collect on the Use a water/detergent mixture For more soiled areas, rinse the Air dry or wipe with a soft clean pergola and will require periodic and a soft clean cloth to clean surface with clean water from top cloth.

  • Page 36: Warranty & Complaints Procedure

    COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty.

  • Page 37: Disassembly And Disposal Of The Product

    DISASSEMBLY AND DISPOSAL OF THE PRODUCT Incorrect disassembly of the pergola may lead to serious injury and product damage. Disassembly should be assigned to qualified personnel with adequate training within the scope of occupational health and safety and knowledge within the scope of recycling.

  • Page 38: Certification Information

    Declaration of performance (DOP) Reference no. DOP0001 Product name and type Mirador Pergola and Mirador Wall Pergola/ pergola awning Model name/ Unique identification code of the product: 111 Deluxe AxBm, 111 Deluxe e AxBm, 111 Deluxe e-Motion RC AxBm, 111 Deluxe e-Motion AxBm,...
