- Page 1 SIDE SHADE SCREEN INSTRUCTION MANUAL...
- Page 2 THANK YOU FOR PURCHASING THE MIRADOR SIDE SHADE SCREEN! This manual will provide you with clear and detailed instructions on how to safely and correctly assemble and maintain your side shade screen, to ensure it brings you many years of use and enjoyment.
-
Page 3: Table Of Contents
TABLE OF CONTENTS - Before Assembling Your Side Shade Screen - Important Safety Advice - List of Parts - Assembly - Operating Your Side Shade Screen - Care & Maintenance - Warranty & Complaints Procedure... -
Page 4: Before Assembling Your Side Shade Screen
BEFORE ASSEMBLING YOUR SIDE SHADE SCREEN WARNING: Improtant safety instructions. Follow all instructions, since incorrect installation can lead to severe injury. Make sure you have all the tools required for assembling your side shade screen In order to assemble your side shade screen safely and correctly, please ensure you have access to the following tools and accessories, all of which are not provided. -
Page 5: Important Safety Advice
IMPORTANT SAFETY ADVICE For the safety of all persons assembling and using the side shade screen , it is important to follow the safety guidelines below. Lift the screen during snowfall rainy or Always wear appropriate work shoes, Work well away from power lines, If using power tools or a ladder, windy days to prolong the servicelife gloves and eye protection when... - Page 6 Keep clothing and body parts away Install on non-Mirador branded After prolonged use we Only use replacement parts that are from the side shade screen to pergola will void the product recommend you check all the approved by the manufacturer.
-
Page 7: List Of Parts
LIST OF PARTS Part Name Right side panel Left side panel Roller Screw 12+3 ST5.5x16mm Baffle Screw ST4.2x20mm Drill Bit ф4x55mm Hex key... -
Page 8: Assembly
ASSEMBLY 1. Component disassembly Assembly Video Using hex hey , remove the built- in screws and washers at both ends of the roller Notice: The unscrewed screws and washers will be used in step . Please keep them properly. Unscrew screws and worm gearbox from the right side panel Notice:... - Page 9 2. Side panel and roller assembly Lay 2 side panels ( & ) and roller on the floor. Insert zipper teeth on both sides into corresponding plastic rails simultaneously, and fix them with baffle and screw , using a phillips screwdriver.
- Page 10 Fix the roller and the worm gearbox to the right side panel Assemble the side panels ( & and roller with screw and gasket on each side, using a hex key...
- Page 11 3. Side shade screen assembly This phase requires two persons and at least two stepladders. Make sure that the stepladders are standing securely to avoid falling. Only use ladders suitable for this kind of installation work. Use a leveler to measure against both of the inner sides to ensure that the corner pillar is straight and level.
- Page 12 Adjust the position to ensure that the side panels ( & ) are parallel to the pillars. Using tape measure to check if the distance from both edge of the side panels ( & ) to the pergola’s pillar is the same. Size (m/ft) (mm)
- Page 13 Adjust the side panels to ensure they are parallel to the pillars. Drill the remaining holes and fix with screws after the appropriate location is determined, using a electric screwdriver. Notice: Remember to tighten the top screws completely. x 10 Remove the crank from the pergola and use the same crank to operate the side shade screen.
- Page 14 4. End of assembly...
-
Page 15: Operating Your Side Shade Screen
OPERATING YOUR SIDE SHADE SCREEN To open the side shade screen, turn the crank handle clockwise; To close the side shade screen, turn the crank handle counter clockwise. Enjoy your new side shade screen and pergola! -
Page 16: Care & Maintenance
CARE & MAINTENANCE Dust and dirt will collect on the screen and Use a water/detergent mixture and a soft Air dry or wipe with a soft clean cloth. will require periodic cleaning. clean cloth to clean the screen. In coastal areas, it is recommended that you For more soiled areas, rinse the surface with Do not use any petroleum based spray frequently spray the screen with water to... -
Page 17: Warranty & Complaints Procedure
COMPLAINTS PROCEDURE For terms and conditions of our limited warranty, please visit www.miradoroutdoor.com or contact your local Mirador sales representative. Complaints procedure: • The complaint must include an order number or transaction number. Goods without an order number or transaction number are not covered under the warranty. - Page 18 Mirador Guided roller blind/ Roller blind Model name/ Unique identification code of the product: 111 Curtain A Am, 111 Curtain B Am, 111 Curtain C Am, for 3x3, for 3x3.6, for 3x4, for 3x5.3, for 3x6, for 3x7.2 for 3.6x3.6, for 3.6x4, for 3.6x5.3, for 3.6x6, for 3.6x7.2 88 Curtain A Am, 88 Curtain B Am, 88 Curtain C Am, for 3x2, for 3x2.4, for 3x3, for 3x4, for 3x5, for 3x6...
