The following is needed:
• A Phillips screwdriver for installation of the M12 protection bracket
• Four M5 × 0.8 screws conforming to the table above
• Installation tool for mounting screws
Do the following:
1. Unpack and check the delivery. If damage is found, notify the supplier.
NOTE
Place the BoX2 device on a stable surface during installation. Dropping the
device or letting it fall may cause damage.
2. Attach UL certified and approved cables\connectors to the BoX2 device. Special precaution must
be followed to ensure approved cable\connector sets are installed according to the environment
and application where the device will be located. The unit is certified to be installed in the
following hazardous environments:
• C1D2, Type 4X
• ATEX\IECEx Zone 2
NOTE
Please refer to the following tables for information on which connectors \ cables
are to be used in each of these two environments.
NOTE
For information, see table ATEX \ IECEx Zone 2 Environment (M12 cables sets)
and Type 4X, C1D2 Environments (M12 connector with cable gland) below.
NOTE
M12 connector with cable gland torque: 3 Nm.
3. Drill the correct hole pattern in device outlined above or install unit on VESA compliant mounting
bracket.
