2.1.1. Protective Connector Shield Installation Process
Do the following:
1.
Install the protective connector shield as shown.
Beijer Electronics, MAEN276
Manufacturer
Description
Model No.
99-3729-995-04
X2 extreme
Connector, M12
SS 4p male 5.5 -
7.5 mm Gland
(LAN)
99-1430-992-04
X2 extreme
Connector, M12
SS 4p female
5.5 - 7.5 mm
Gland (Power)
11
Installation
Cable Ratings
2023-09
