Device Drawings

5. Device Drawings

5.1. Connectors

Pos Connector
1

Power supply

2 COM B
3 USB 1+ USB 2
4 LAN A
5 LAN B
6 COM A
5.2. Connectors
2 3
1
Pos Connector
1 Power supply
2 LAN A
3 LAN B
4 COM
5.2.1. Power Supply
Pin
1 V +
in
2 V -
in
3 V -
in
4 V +
in
2023-09
+24 V DC
Serial communication port
USB Host 2.0, max output current 500 mA
1 × 10/100 Base-T
1 × 10/100 Base-T
Serial communication port
4
+24 V DC (18–32 V DC)
1×10/100 Base-T (shielded RJ45)
1×10/100 Base-T (shielded RJ45)
Serial communication port
Description
16
Description
Description
M12. 4 pin male
