- Page 1 PXIe-5655 Safety, Environmental, and Regulatory Information PXIe, 7.2 GHz PXI RF Analog Signal Generator...
-
Page 2: Safety, Environmental, And Regulatory Information
PXIe-5655 Safety, Environmental, and Regulatory Information Safety, Environmental, and Regulatory Information Read this document before you install, configure, operate, or maintain this product. Users are required to familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards. -
Page 3: Safety Guidelines
PXIe-5655 Safety, Environmental, and Regulatory Information Caution: Possibility of Electric Shock —Take precautions to avoid electrical shock. ESD Sensitive —Take precautions to avoid damaging the product with electrostatic discharge. Safety Guidelines CAUTION Observe all instructions and cautions in the user documentation. - Page 4 PXIe-5655 Safety, Environmental, and Regulatory Information Absolute maximum reverse power +18 dBm (LO 0/1 OUT) Maximum input voltage (REF IN) 3.3 V pk-pk Measurement Category CAT I/O ni.com...
-
Page 5: Measurement Category
PXIe-5655 Safety, Environmental, and Regulatory Information Measurement Category WARNING Do not connect the product to signals or use for measurements within Measurement Categories II, III, or IV, or for measurements on MAINs circuits or on circuits derived from Overvoltage Category II, III, or IV which may have transient overvoltages above what the product can withstand. - Page 6 PXIe-5655 Safety, Environmental, and Regulatory Information transitoires dépassent la surtension transitoire nominale. Une analyse des tensions de fonctionnement, des impédances de boucle, des surtensions temporaires et des surtensions transitoires dans le système doit être effectuée avant de procéder à des mesures.
-
Page 7: Emc Guidelines
PXIe-5655 Safety, Environmental, and Regulatory Information EMC Guidelines This product was tested and complies with the regulatory requirements and limits for electromagnetic compatibility (EMC) as stated in the product specifications. These requirements and limits are designed to provide reasonable protection against harmful interference when the product is operated in its intended operational electromagnetic environment. - Page 8 PXIe-5655 Safety, Environmental, and Regulatory Information EMC Notices Refer to the following notices for cables, accessories, and prevention measures necessary to ensure the specified EMC performance. NOTICE For EMC declarations and certifications, and additional information, refer to the Product Certifications and Declarations section.
-
Page 9: Electromagnetic Compatibility Standards
PXIe-5655 Safety, Environmental, and Regulatory Information NOTICE This product may become more sensitive to electromagnetic disturbances in the operational environment when test leads are attached or when the product is connected to a test object. NOTICE Operate this product only with shielded cables and accessories. -
Page 10: Environmental Guidelines
PXIe-5655 Safety, Environmental, and Regulatory Information • EN 61326-1 (IEC 61326-1): Class A emissions; Basic immunity • EN 55011 (CISPR 11): Group 1, Class A emissions • AS/NZS CISPR 11: Group 1, Class A emissions NOTE Group 1 equipment (per CISPR 11) is any... -
Page 11: Environmental Characteristics
PXIe-5655 Safety, Environmental, and Regulatory Information Environmental Characteristics Temperature and Humidity Temperature Operating Chassis with slot 0 °C to 55 °C cooling capacity ≥58 W Chassis with slot 0 °C to 40 °C cooling capacity ≥38 W Humidity Operating 10% to 90%, noncondensing... -
Page 12: Environmental Standards
PXIe-5655 Safety, Environmental, and Regulatory Information Shock and Vibration Random vibration Operating 5 Hz to 500 Hz, 0.3 g RMS Non-operating 5 Hz to 500 Hz, 2.4 g RMS Operating shock 30 g, half-sine, 11 ms pulse Environmental Standards This product meets the requirements of the following environmental standards for electrical equipment. -
Page 13: Power Requirements
PXIe-5655 Safety, Environmental, and Regulatory Information High temperature limits for operation ◦ Class 4, for storage Class 3 Random vibration limits for non- ◦ operating Class 3 Shock limits for operating Class 2 ◦ NOTE To verify marine approval certification for a product, refer to the product label or visit ni.com/... -
Page 14: Export Compliance
PXIe-5655 Safety, Environmental, and Regulatory Information Export Compliance This product is subject to control under the U.S. Export Administration Regulations (15 CFR Part 730 et. seq.) administered by the U.S. Department of Commerce's Bureau of Industry and Security (BIS) (www.bis.doc.gov) and other applicable U.S. - Page 15 PXIe-5655 Safety, Environmental, and Regulatory Information EU and UK Customers Waste Electrical and Electronic Equipment (WEEE) —At the end of the product life cycle, all NI products must be disposed of according to local laws and regulations. For more information about how to recycle NI products in your region, visit ni.com/environment/weee.
- Page 16 PXIe-5655 Safety, Environmental, and Regulatory Information NI Services Visit ni.com/support to find support resources including documentation, downloads, and troubleshooting and application development self-help such as tutorials and examples. Visit ni.com/services to learn about NI service offerings such as calibration options, repair, and replacement.
- Page 17 PXIe-5655 Safety, Environmental, and Regulatory Information © National Instruments Corporation...
- Page 20 Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end- user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade...
