IMPORTANT
1. Refrigerant charging should only be carried out
by an EPA-certified air conditioning contractor.
2. This appliance is not intended to be operated
or serviced by persons (including children) with
reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless
they have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
3. Children should be supervised to ensure that
they do not play with the appliance.
IMPORTANT
1. L'ajout de frigorigène doit être confié à un
spécialiste de la climatisation certifié par
l'agence de la protection de l'environnement
(EPA) du gouvernement américain.
2. Cet appareil n'est pas conçu pour être utilisé
ou entretenu par des personnes (y compris
des enfants) dont les capacités physiques,
sensorielles ou mentales sont réduites, ou qui
n'ont pas l'expérience et les connaissances
suffisantes, à moins d'être supervisées ou
d'avoir obtenu des directives concernant
l'utilisation de l'appareil par une personne
responsable de leur sécurité.
3. Les enfants doivent être supervisés pour
s'assurer qu'ils ne jouent pas avec l'appareil.
INSPECTION ON ARRIVAL
1. Inspect unit upon arrival. In case of damage, report
immediately to transportation company and your local factory
sales representative.
2. Check serial plate on unit to verify that the power supply
meets available electric power at the point of installation.
3. Inspect unit upon arrival for conformance with description of
product ordered (including specifications where applicable)
2

TABLE OF CONTENTS

Special Precautions
Hazard Intensity Levels ........................................................3
Special Design Requests
Unit Location ........................................................................6
Unpacking ..........................................................................6
Blank Off Pieces
Preparation ........................................................................6
Ceiling Opening Sizes ........................................................6
Positioning Wall Mounted Thermostat
Installation ............................................................................8
Hanger Bolts ......................................................................8
Installation Guide
Condensate Piping .............................................................9
Duct Collars .......................................................................9
Piping Installation
Wiring ...............................................................................11
Disconnect Switch ............................................................12
Terminal Strip Connections
Remote Condensing Unit Terminal Strip Connections
Fascia Assembly
Start-Up Procedure
Start Up Sheet - Example
Sequence of Operation
Micro-Processor Operation
Dimensions ........................................................................20
Small Chassis: Chilled Water Units
Medium Chassis: Chilled Water Units ..............................21
Large Chassis: Chilled Water Units
Medium Chassis: DX and Heat Pump units
Large Chassis: DX and Heat Pump units
DX Cooling Only and Heat Pump Units - IP Units
DX Cooling Only and Heat Pump Units - SI Units
Chilled Water Units - IP Units ...........................................28
Chilled Water Units - SI Units
Exploded Unit Drawing & Parts List - Chilled Water
Exploded Unit Drawing & Parts List - DX & Heat Pump ....31
Maintenance ......................................................................32
Disassembly Procedure
Replacement Parts
Model Identification
Troubleshooting .................................................................35
8-504.11
.............................................................3
.....................................................5
................................................................6
...............................7
...............................................................8
.............................................................10
..............................................12
..............................................................12
............................................................13
..................................................14
......................................................16
................................................18
.................................20
.................................22
.....................23
........................24
..........................................29
...................................................33
..........................................................33
............................................................34
.....12
...........26
...........27
.........30
