  • Page 1 AMBERAIR ELECTRICAL INSTALLATION, OPERATION AND MAINTENANCE MANUAL...

  • Page 2: Table Of Contents

    1. CONTENTS 2. SAFETY PRECAUTIONS 3. FANS 3.1 FANS WITH AC MOTORS (1 SPEED) 3.2 FANS WITH AC MOTORS (2 SPEED) 3.3 FANS WITH EC MOTORS 3.4 FANS WITH PM MOTORS 3.4.1 VSD INTEGRATED ON MOTOR 3.4.2 VSD DELIVERED LOOSE (FC101 AND FC102) 4.
  • Page 3 2. SAFETY PRECAUTIONS • All work in connection with the assembly, installation and commissioning of the unit must be carried out by specially trained personnel. The unit can only be taken into operation if it has been assembled in accordance with these installation and operation manual. All protective devices must be effective.

  • Page 4: Fans

    3. FANS Direct-driven centrifugal fans (plug fans) with one of the following motor: • AC motor; • EC motor; • PM motor. Important: Electrical connection may only be undertaken by technically trained personnel. Before making the electrical motor connections, compare the connection specifications with the specifications on the motor identification plate. Identification plate is attached on the inner side of the motor cover or provided in the technical table on the motor.
  • Page 5 General: Before starting any inspection work, fans must be disconnected from voltage and all safety requirements must be followed. Possible solutions if the fan does not rotate: • Check connectors and contacts; • Check if the electrical connection of the motor is correct; •...
  • Page 6 Mains connection; (5) - Connection alarm relay; (6) - Connection contols; (7) - Slot for add-on module. Cable connection procedure: 1. Remove the cover from the controller housing for the connection. 2. All 3 cable entry points are in a sealed condition at delivery. Remove plastic fastener if necessary, and insert enclosed cable glands, entry points that are not used must remain sealed! 3.
  • Page 7 energized, 11 - Normal operation without fault 14 bridged energized, 11 - no enable = OFF Switch OFF by external contact (digital input). 14 bridged Terminals “D1” - “24 V / 10 V” (Digital In 1) not bridged energized, 11 - Active temperature management With a drop in temperature the modulation rises again llinear.
  • Page 8 14 x de-energized, Error Peak current After a switch off the controller waits for 5 seconds then the 11 - 14 inter- If the motor current increases above the controller attempt a start. rupted specified limit (even in a short time- Arises within 60 sec.

  • Page 9: Fans With Pm Motors

    NOTE: Breakdown of EC fan can only be recognized via fault relay. • Control with UNIcon as MODBUS Master All EC fans are equipped with AM-MODBUS modules. NOTE: Breakdown of EC fan can be recognized via MODBUS communication line. NOTE: For both control types an external control signal is needed. For more information, control, maintenance, diagnostics and troubleshooting refer to EMR‘ex and UNIcon technical specification.
  • Page 10 Figure 3.4.1.1 – PM motor with VSD integrated on motor Built-on frequency controller and PM motor connection diagram Figure 3.4.1.2 Built-on frequency inverter and PM motor connection diagram: (1) – PM motor; (2) – Frequency converter; (3) – Remote control (hand terminal). Built-in protection If the temperature inside frequency converter exceeds +95°C, the frequency converter will attempt to reduce its internal heat generation by reduc- ing motor speed (rpm).

  • Page 11: Vsd Delivered Loose (Fc101 And Fc102)

    3.4.2 VSD DELIVERED LOOSE (FC101 AND FC102) FC101 and FC102 frequency converters are delivered loose. They are to be mounted by the customer. Figure 3.4.2.1 – PM motor speed controller: (1) - FC101 Frequency controller; (2) - FC102 Frequency controller; Separate speed controller should be mounted near the fan.
  • Page 12 Digital input *PNP/NPN Coast inverse Digital input *PNP/NPN +10 V output Analog input *0-10 V/0-20 mA/ 4-20 mA Ref1 Analog input *0-10 V/0-20 mA/ 4-20 mA Ref2 12 bit *0-20 mA/4-20 mA/DO Analog 12 bit *0-20 mA/4-20 mA/DO Analog 1, 2, 3 Relay 1 1,2 NO 1,3 NC [9] Alarm...

  • Page 13: Cable Selection And Cable Instalation

    4. CABLE SELECTION AND CABLE INSTALATION 4.1 THREE PHASE RECEIVER POWER SUPPLY CABLE SELECTION Various conditions must be evaluated before selecting cable cross-section area: • Power; • Current; • Starting currents; • Operating conditions; • Voltage drop; • Mounting type; •...

  • Page 14: Heat Recovery Systems

    5. HEAT RECOVERY SYSTEMS 5.1 PLATE HEAT EXCHANGER In the plate heat exchanger, the warm extract air and the cool fresh air, separated by thin plates, pass each other in counter-flow. No mixing of the two air streams takes place. Therefore, the transmission of dirt, odours, moisture, bacteria, etc. is impossible. Heat transmitted from extract air to fresh air purely by conduction because of the temperature difference between the two air streams: the warm extract air cooled down and the cool fresh air heated up.
  • Page 15 By-pass actuator electrical instalation NOTE: For more information, control, maintenance, diagnostics and troubleshooting refer to actuator technical specification. For indoor swimming pool premises, by-pass damper actuator is selected with higher protection class (IP66/67). Optimum protection against corrosion and chemical influences, UV radiation, damp and condensation. Figure 5.1.4 –...

  • Page 16: Rotary Heat Exchanger

    Figure 5.1.5 – Palate heat exchanger pressure switch and tubes mounting principal scheme: GP3 – Heat exchanger pressure switch (relay) with „+“ and „-“ pressure tubes; ST3 – By-pass damper aqtuator; (1) – Supply air flow; (2) – Fresh air flow; (3) – Exhaust air flow; (4) – Extract air flow. 5.2 ROTARY HEAT EXCHANGER Rotary heat exchangers are regenerators with rotating heat accumulators.

  • Page 17: Phase Rotor Motor (W/O Control)

    Recommended cable cross-sectional area (mm2) for connecting 1-phase rotor motor: CABLE CONDUCTOR CROSS-SECTIONAL AREA, mm PURPOSE Motor power supply cable NOTE: Rotor motor must be grounded. Ground wire must be connected to the ground screw at the motor junction box, and the other end of the wire must be connected to the ground loop of the device.

  • Page 18: Stepping Motor With Controller

    General: If rotor does not rotate, check if: • All cable connections (is any) are connected; • Rotor motor is properly connected; • Power supply voltage matches voltage indicated on the rotor motor plate; • Thermal protection of the motor is activated (if any). When thermal protection is activated, contact becomes open (NO). After starting the device, inspect: •...
  • Page 19 OJ-DRHX-2-8Nm Figure 5.2.3.1 – stepmotor controller OJ-DRHX-2-8Nm DESCRIPTION DESCRIPTION Test button RJ12 Modbus connector (2 x RJ12) 4-pole DIP switch A/D control and signal terminals, depending on variant Supply terminals (L, N, PE) 3 x 7-segment display - depending on variant Connection terminals for stepper motor (U, V, W, PE) Figure 5.2.3.2 –...
  • Page 20 DESCRIPTION DESCRIPTION Stepper motor connections (U, V, W, PE) RJ12 Modbus connector Connection terminals for future use 3-point strain relief for Modbus cable (ribbon cable) Connector for optional module Supply terminals (L, N, PE) Terminal strip for Modbus and A/D control signals Earth connection (PE) Figure 5.2.3.4 –...
  • Page 21 Connector terminals, stepper motor and extension cable Check that the connector terminals between the stepper motor cable and the extension cable are properly assembled and correctly en- gaged. The connector is properly assembled when the locking pawl on both sides of the connector on the motor cable is in firm connection with the connector on the extension cable.
  • Page 22 Figure 5.2.3.6 – rotation sensor mounting: (1) – Rotor heat exchanger; (2) – Rotation sensor; (3) – Magnet; The control unit is protected by monitoring for both over-voltage and undervoltage. If the supply voltage goes over or under the allowed limits, an alarm is triggered and the motor stops.

  • Page 23: Heat Exchangers

    General for step motor drives: Probable fault cause on installation: • Magnet turned the wrong way • Magnet transmitter incorrectly connected (wrong polarity), see electrical connection; • Too big a gap between magnet transmitter and magnet; Probable fault cause in operation: •...
  • Page 24 Figure 6.1.3 – Water valve actuator (SAX…) manual override When pushing the manual adjuster down (1), it engages and the actuator can be manually operated. When turning the manual adjuster in a clock- wise/counterclockwise direction (2), the actuator’s stem extends/retracts. NOTE: For more information, control, maintenance, diagnostics and troubleshooting refer to water circulation pump and water valve actuator technical specification.

  • Page 25: Water Cooler

    6.2 WATER COOLER The water cooler designed for cooling air with fluid as the cold carrier and mounted in the unit. Water cooler sections can be supplied with cold carrier temperature control point RMG. In case of built-in automation, connection of the water circulator pump and the three-way valve with actuator is designed.

  • Page 26: Gas-Fired Heater

    • All steps of the electric heater operates; • Thermal protections are not activated; • Circuit breaker is not switched off (because of current overload); • Cables and wires do not touch heating elements; • The cables and wires do not melt; Establishment of malfunctions: MALFUNCTION REASON OF MALFUNCTION...

  • Page 27: Humidifiers

    7. HUMIDIFIERS 7.1 STEAM HUMIDIFIER Immersed electrode humidifier for comfort air conditioning applications. Humidifier consist of humidifier cabinet placed near air handling unit and steam distributors installed inside air handling unit section with stainless steel drip tray or inside air ductwork. Two humidifier types available: X-plus and Basic.

  • Page 28: Air Filter Section

    8. AIR FILTER SECTION The air filters in a ventilation system prevent dust and other impurities reaching the premises. They also protect sensitive components in the air handling unit, such as air heaters, coolers and heat exchangers from contamination. Changing of filter should be primarily based on clogging, indicated by final pressure drop. Both visual inspection and monitoring of pressure drop is recommended.

  • Page 29: Damper Section

    9. DAMPER SECTION The function of dampers is to control air supply to ducts, to close unit when the system is off, to prevent cold air to get in to the premises. Damper can be controlled manually with handle or automatically with actuator. Damper actuator control types: open / close or modulating (0-10V).
  • Page 30 Actuator electrical instalation NOTE: For more information, control, maintenance, diagnostics and troubleshooting refer to actuator technical specification. For indoor swimming pool premises, damper actuator is selected with higher protection class (IP66/67). Optimum protection against corrosion and chemical influences, UV radiation, damp and condensation. Figure 9.4 –...

  • Page 31: Control System

    10. CONTROL SYSTEM Control equipment customized according to every special customer need. All AmberAir units ordered with control system are factory configured and tested together with all the necessary field components. Control system types: • Built in control system. All components are in control section.
  • Page 32 IMPORTANT: Control system must be grounded. Ground terminal is labeled with “PE” or symbol NOTE: Connecting power supply cable to the main switch make sure cable wires are tightened and secured from toutching each other. During control system check inspect for power supply cable loose. General Before power supply is switched on to the control system, make sure: •...

  • Page 33: Accessories

    11. ACCESSORIES 11.1 FAN SAFETY SWITCH Safety switches are designed to be mounted near a motor to isolate it from the main circuit. They prevent accidental starting of electrical motor during maintenance or repair work. When safety switch in “OFF“ position, it can be locked with a lock. Figure 11.1.1 –...

  • Page 34: Co Duct And Room Sensor (With Integrated Control System)

    devices (e.g. smoke detectors). Units with control system can be equipped with smoke detector. Smoke detector has been developed to detect smoke in ventilation ducts. The duct detector contains an intelligent controlling circuit. This circuit is adjusting the sensitivity to give an optimal function during the whole life time of the detector.

  • Page 35: Unit Assembling

    12. UNIT ASSEMBLING If unit is with integrated control system, cable connectors must be connected between sections: • Place unit section close to each other (approximately 0,2 m). • Connect cable connectors. • Every cable connector marked with numeric label. •...

  • Page 36: Unit's Base Frame Grounding

    13. UNIT’S BASE FRAME GROUNDING Fully assembled unit‘s base frame must be grounded: • Between base frames (Example: General grounding diagram – D); • Base of the fully assembled unit must be connected with the building grounding system (Example: General grounding diagram – F); Figure 13.1 –...

  • Page 37: Checklist For Unit Start-Up And Maintenance

    14. CHECKLIST FOR UNIT START-UP AND MAINTENANCE Periodically check, clean and repair (if necessary) all AHU components. Proper maintenance ensures a long service life of the unit. Document and keep all maintenance works journal in a well-known place. • Device can be started only by trained and qualified personnel; •...
  • Page 38 Control cabinet ** Check if the control cabinet is firmly installed on the device (when integrated externally). Check if there are no signs of damage outside and inside the control cabinet. Electrical components are not damaged and in place. Check if there are no foreign objects, waste, moisture or water inside the cabinet. If yes, remove. Check if the cables inside the control cabinet are connected in accordance with the basic connection diagram.
  • Page 39 EIOM v2018.04...
