proform.com Model No. PFTL97718.1 USER’S MANUAL Serial No. Write the serial number in the space above for reference. Serial Number Decal ACTIVATE YOUR WARRANTY To register your product and activate your warranty today, go to my.proform.com. CUSTOMER CARE For service at any time, go to proformservice.com.
Note: The decals may not be shown at actual size. PROFORM and IFIT are registered trademarks of ICON Health & Fitness, Inc. App Store is a trademark of Apple Inc., registered in the U.S. and other countries. Android and Google Play are trademarks of Google Inc. The BLUETOOTH word mark and logos are registered trademarks of Bluetooth SIG, Inc.
To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
Page 4
19. Always stand on the foot rails when starting able to safely lift 45 lbs. (20 kg) to move the or stopping the walking belt. Always hold the treadmill. handrails while using the treadmill. 26. When folding or moving the treadmill, make 20.
BEFORE YOU BEGIN Thank you for selecting the new PROFORM ® reading this manual, please see the front cover of this COACHLINK T 9.0 treadmill. The COACHLINK T 9.0 manual. To help us assist you, note the product model treadmill provides an impressive selection of features number and serial number before contacting us.
PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.
ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 7. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you fi...
Page 9
2. Make sure that the power cord is unplugged. Remove the tie securing the Upright Wire (80) to the front of the Base (88). Next, identify the Right Upright (79). Have a second person hold the Right Upright near the Base (88).
Page 10
4. Set the Right Upright (79) on the Base (88) as shown. Make sure not to pinch the Upright Wire (80). Slide the Right Upright so that the 3/8" x 2 3/8" Screw (2) in the Base is inserted into the slot in the Right Upright. Do not tighten the Screw yet.
Page 11
6. Remove and save the four indicated 5/16" x 3/4" Screws (13). 7. Attach a Handrail (72) to the Right Upright (79) with two 5/16" x 2" Screws (5) and two 5/16" Star Washers (7); start both Screws, and then tighten them.
Page 12
8. Attach the other Handrail (72) to the Left Upright (78) with two 5/16" x 2" Screws (5) and two 5/16" Star Washers (7); start both Screws, and then tighten them. Then, remove and discard the two indicated screws (E). 9.
Page 13
10. Set the Upright Tray (90) on the Upright Crossbar (77). Attach the Upright Tray with four #8 x 3/4" Screws (11); start all four Screws, and then tighten them. Do not overtighten the Screws. 11. Set the Console Base (74) face down on a soft surface to avoid scratching the Console Base.
Page 14
12. IMPORTANT: To avoid damaging the Pulse Crossbar (75), do not use power tools and do not overtighten the #10 x 3/4" Screws (9). Orient the Pulse Crossbar (75) as shown. Attach the Pulse Crossbar to the Handrails (72) with four #10 x 3/4"...
Page 15
14. Set the console assembly (G) on the Handrails (72). Make sure that no wires are pinched. Insert the excess Upright Wire (80) into the con- sole assembly (G). Next, tighten the two ties (I) around the Upright Wire, and cut off the ends of the ties.
Page 16
16. Set the Left Handrail Cover (70) on the left Handrail (72). Start two #8 x 3/4" Screws (11) into the left Handrail and the Left Handrail Cover. Next, slide the Left Handrail Cover forward against the console assembly (G) as shown. Then, tighten both Screws.
Page 17
18. Press the two tabs on the Tablet Holder (26) into the slots (K) in the console assembly (G). Attach the Tablet Holder (26) with four M4 x 16mm Screws (24). Note: Start the two top Screws fi rst, and then start the two bottom Start First Screws.
Page 18
20. IMPORTANT: You must activate your Console (31) to begin using its exclusive features. First, plug in the power cord (see page 19) and turn on the power (see page 21). Then, using your smartphone or tablet, go to iFit.com/activate and follow the instructions to activate the Console (31).
HOW TO USE THE TREADMILL HOW TO CONNECT THE POWER CORD more amps. To avoid overloading the circuit, do not plug other electrical devices, except for low- Use a Surge Suppressor power devices such as cell phone chargers, into the surge suppressor or into an outlet on the same Your treadmill, like other electronic equipment, can be circuit.
Page 20
CONSOLE DIAGRAM FEATURES OF THE CONSOLE You can even listen to your favorite workout music or audio books with the console’s sound system while you IMPORTANT: To activate your console and begin exercise. using its exclusive features, see assembly step 20 on page 18.
Page 21
HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
Page 22
4. Change the incline of the treadmill as desired. Vertical Distance (VRT FT or VRT M)—The distance you have walked or run in vertical feet or To change the incline of the treadmill, press the vertical meters. Incline increase and decrease buttons or one of the numbered Quick Incline buttons.
Page 23
6. Measure your heart rate if desired. HOW TO USE AN ONBOARD WORKOUT You can measure your heart rate using either the 1. Insert the key into the console. handgrip heart rate monitor or a compatible heart rate monitor. For information about purchasing See HOW TO TURN ON THE POWER on page 21.
Page 24
To stop the workout at any time, press the Stop HOW TO CONNECT YOUR TABLET TO THE button. To restart the workout, press the Start but- CONSOLE ton. The walking belt will begin to move at 1 mph. When the next segment of the workout begins, the The console supports BLUETOOTH connections treadmill will automatically adjust to the speed and to tablets via the iFit Smart Cardio Equipment app...
Page 25
4. Record and track your workout information. THE SETTINGS MODE Follow the instructions in the iFit Smart Cardio 1. Select the settings mode. Equipment app to record and track your workout information. To select the settings mode, press the Settings button.
Page 26
Display Test—This screen is intended to be used Contrast Level—The currently selected contrast by service technicians to identify whether the level will appear in the display. Press the Incline display is working correctly. increase and decrease buttons to adjust the contrast level.
Page 27
HOW TO USE THE SOUND SYSTEM HOW TO USE THE TABLET HOLDER To play music or audio books through the console IMPORTANT: The tablet holder is designed for use sound system while you exercise, plug a 3.5 mm male with most full-size tablets. Do not place any other to 3.5 mm male audio cable (not included) into the jack electronic device or object in the tablet holder.
FCC INFORMATION This console has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at to zero before you fold the treadmill. Then, remove the left.
MAINTENANCE AND TROUBLESHOOTING MAINTENANCE b. After the power cord has been plugged in, make sure that the key is inserted into the console. Regular maintenance is important for optimal per- formance and to reduce wear. Inspect and properly c. Check the power switch located on the treadmill tighten all parts each time the treadmill is used.
Page 31
SYMPTOM: The incline of the treadmill does not c. Your treadmill features a walking belt coated with change correctly high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to a. Calibrate the incline system (see step 3 on page 25). the walking belt or the walking platform unless instructed to do so by an authorized service SYMPTOM: The walking belt slows when walked on...
Page 32
SYMPTOM: The walking belt slips when walked on SYMPTOM: The tablet holder does not stay in place a. First, remove the key and UNPLUG THE POWER a. Rotate the tablet holder until it faces backward. CORD. Using the hex key, turn both idler roller Then, tighten the indicated screw slightly until the screws clockwise, 1/4 of a turn.
EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.
PART LIST Model No. PFTL97718.1 R0118A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Plastic Tie 3/8" x 2 3/8" Screw Latch Plate 3/8" x 1 1/4" Screw Storage Latch 3/8" x 1 1/2" Screw Motor Belt 5/16"...
Page 35
Key No. Qty. Description Key No. Qty. Description M8 x 102mm Bolt M8 Flange Nut M8 x 20mm Bolt – User’s Manual M8 Star Washer Note: Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.
This warranty extends only to the original purchaser (customer) and is not transferrable. ICON’s obliga- tion under this warranty is limited to repairing or replacing, at ICON’s option, the product through one of its authorized service providers. All repairs for which warranty claims are made must be preauthorized by ICON.
