10. Set the Upright Tray (90) on the Upright
10
Crossbar (77). Attach the Upright Tray with four
#8 x 3/4" Screws (11); start all four Screws,
and then tighten them. Do not overtighten the
Screws.
90
77 11
11
11. Set the Console Base (74) face down on a soft
11
10
surface to avoid scratching the Console Base.
86
10
Remove and discard the two indicated screws
10
(F). Then, remove the Pulse Crossbar (75).
85
Next, identify the Left and Right Trays (85, 86).
10
13
Attach the Trays to the Console Base (74) with
eight #8 x 1/2" Screws (10); do not overtighten
the Screws.
Then, remove and save the four indicated
5/16" x 3/4" Screws (13).
F
75
F
74
13
13
