7P HEX IP User Instructions 4 0 1 0 7 6 5...
Page 2
All non-ADJ Products, LLC brands and product names are trademarks or registered trademarks of their respective companies. ADJ Products, LLC and all affiliated companies hereby disclaim any and all liabilities for property, equipment, building, and electrical damages, injuries to any persons, and direct or indirect economic...
TABLE OF CONTENTS Introduction Features I Warranty Registration I Installation Safety Precautions IP Notice Layout DMX Set Up DMX Addressing DMX Channel Modes Color Macro Chart System Menu Operating Instructions Primary-Secondary Configuration Dimmer Mode Chart I Dimmer Curve Chart Dimensional Drawings Power Linking I Trouble Shooting I Cleaning Limited Warranty (USA Only) Technical Specifications...
INTRODUCTION Unpacking: Thank you for purchasing the 7P Hex IP by ADJ Products, LLC. Every 7P Hex IP has been thoroughly tested and has been shipped in perfect operating condition. Carefully check the shipping carton for damage that may have occurred during shipping. If the carton appears to be damaged, carefully inspect your fixture for any damage and be sure all accessories necessary to operate the unit has arrived intact.
Page 5
FEATURES • Multi-Colors • Five Operating Modes • Electronic Dimming 0-100% • DMX-512 protocol • IP65 Locking 3-Pin XLR Connections In/Out • Four DMX Modes: 6 Channel Mode, 7 Channel Mode, 8 Channel Mode, and 13 Channel Mode. • Multiple Unit Power Linking (See page 24) Included: 1 x IP65 Locking Power Cable WARRANTY REGISTRATION...
SAFETY PRECAUTIONS • Do not attempt to operate this unit if the power cord has been frayed or broken. Do not attempt to remove or break off the ground prong from the electrical cord. This prong is used to reduce the risk of electrical shock and fire in case of an internal short.
Page 7
SAFETY PRECAUTIONS RISK GROUP 3 - RISK OF EXPOSURE TO ULTRAVIOLET (UV) RADIATION! FIXTURE EMITS HIGH INTENSITY ULTRAVIOLET (UV) LIGHT FROM THE UV LED. WEAR PROPER EYE AND SKIN PROTECTION. AVOID PROLONGED PERIODS OF EXPOSURE TO THE UV LED. AVOID WEARING WHITE COLOR CLOTHING AND/OR USING (UV) PAINTS ON SKIN. AVOID DIRECT EYE AND/OR SKIN EXPOSURE AT DISTANCES SHORTER THAN 11 feet (3.3m).
O P T I O N A L C O R R O S I O N - R E S I S T A N T C O A T I N G Optional Corrosion-Resistant Coatings may be available for this fixture. Please consult your ADJ Products, LLC sales representative for details.
DMX SET UP DMX-512: DMX is short for Digital Multiplex. This is a universal protocol used as a form of communication between intelligent fixtures and controllers. A DMX controller sends DMX data instructions from the controller to the fixture. DMX data is sent as serial data that travels from fixture to fixture via the DATA “IN”...
Page 11
2 and 3 of a male XLR connector (DATA + and DATA -). This unit is inserted in the female XLR connector of the last unit in your daisy chain to terminate the line. Using a cable terminator (ADJ part number Z-DMX/T) will decrease the possibilities of erratic behavior. Termination reduces signal errors and...
DMX ADDRESSING All fixtures should be given a DMX starting address when using a DMX controller, so the correct fixture responds to the correct control signal. This digital starting address is the channel number from which the fixture starts to “listen” to the digital control signal sent out from the DMX controller. The assignment of this starting DMX address is achieved by setting the correct DMX address on the digital control display on the fixture.
Page 13
DMX TRAITS & VALUES 13CH 0 -255 0~100% Green 0 -255 0~100% Blue 0 -255 0~100% White 0 -255 0~100% Amber 0 -255 0~100% 0 -255 0~100% Master Dimmer 0 -255 0 ~100% Strobe 0 - 31 LED O 32 - 63 LED On 64 - 95 Strobe Slow - Fast...
SYSTEM MENU Software Version < V1.04 MENU SUB MENU OPTIONS/VALUES (DEFAULT SHADED) DESCRIPTION Update Wait … Display Menu V1.04 Set ADDR Menu 001 -506 DMX Addressing Set ADDR Menu CH06 6/7/8/13 DMX Channel Modes User Mode DimCurve Dimmer Curve Setting Standard /Stage /TV Architec /Theatre Standard NO DMX...
Page 17
SYSTEM MENU Software Version > V1.07 MENU SUB MENU OPTIONS/VALUES (DEFAULT SHADED) DESCRIPTION Update Wait … Display Menu V1.07 Set ADDR Menu 001 -506 DMX Addressing Set ADDR Menu CH06 6/7/8/13 DMX Channel Modes User Mode Dim Mode Dimmer Mode Setting Standard /Stage /TV Architec /Theatre Standard NO DMX...
Page 18
Blue:000~255 White Balance Setting White :000~255 Amber :000~255 SYSTEM MENU UV:000~255 Set LED Refresh Fre_hz 900 /1000/1100/1200/1300/1400/1500/2500/4000/50 Frequency Rate Software Version 00/10k /15k /20k /25k Gamma < V1.08 2.0 / 2.2 / 2.4 / 2.8 Set Gamma Brightness TimeInfo Current Current Running Time (Hours) TimeInfo TotalTim Total Time (Hours)
OPERATING INSTRUCTIONS DMX Addressing: Operating through a DMX controller gives the user the freedom to create their own programs tailored to their own individual needs. The 7P Hex IP has 4 DMX modes: 6 Channel mode, 7 Channel mode, 8 Channel mode, and a 12 Channel mode. 1.
Page 20
OPERATING INSTRUCTIONS Static Color Mode: 1. Access the main menu, and press the UP or DOWN buttons so that “Menu Function” is highlighted, then press ENTER. Use the UP or DOWN buttons to highlight “1. STATC CL:X” and press ENTER. “X” is the current color that is displayed. 2.
Page 21
OPERATING INSTRUCTIONS Unit Temperature - With this function you can switch the temperature setting between celsius or fahrenheit. 1. Plug the fixture in and press the MODE button and press the UP or DOWN buttons until “Menu Function” is displayed, and press ENTER. 2.
OPERATING INSTRUCTIONS Time Information: 1. Plug the fixture in and press the MODE button and press the UP or DOWN buttons until “Menu Info” is displayed, and press ENTER. 2. Press the UP or DOWN buttons to scroll through the different information menus. Press ENTER to access your desired menu.
Page 23
DIMMER MODE CHART DIMMER 100% Time (ms) 0 Sec Rise Time Down Time 0 sec Fade Time 1 sec Fade Time Dimming Mode Ramp E ect Rise Time (ms) Down Time (ms) Rise Time (ms) Down Time (ms) Standard (default) Stage 1100 1540...
Page 25
MULTIPLE UNIT POWER LINKING With this feature you can connect the fixtures to one another using the power input and out- put sockets. The maximum that can be connected is 20 fixtures @ 120V and 37 fixtures @ 240V. After the maximum connected fixtures you will need to use a new power outlet. NOTE: USE CAUTION WHEN POWER LINKING OTHER FIXTURES TO THE 7P HEX IP AS THE POWER CONSUMPTION OF OTHER LIGHTING FIXTURES WILL VARY! TROUBLE SHOOTING...
ADJ Products, LLC factory unless prior written authorization was issued to purchaser by ADJ Products, LLC; if the product is damaged because not properly maintained as set forth in the instruction manual.
