DEMO MANUAL DC1529A

parts List

ITEM QTY REFERENCE
Required Circuit Components
1 3 C6, C7, C8
2 0 C1, C4 (Opt.)
3 0 C2 (Opt.)
4 0 C3, C5 (Opt.)
5 15 E1-E15
6 0 PAD1, PAD2
7 3 JP3-JP5
8 1 JP2
9 1 JP1
10 5 FOR (JP1-JP5)
11 1 J1
12 3 R1-R3
13 0 U1 (Opt.)
14 0 U2 (Opt.)
15 1 U4
DC1529A-A Required Circuit Components
16 1 U3
DC1529A-B Required Circuit Components
16 1 U3
4
PART DESCRIPTION
CAP., CHIP X7R 0.1µF 16V 0603
CAP., CHIP X7R 0.1µF 16V 0603
CAP., CHIP X5R 4.7µF 6.3V 0805
CAP., CHIP X5R 10µF 6.3V 0805
TURRET, TESTPOINT 0.064"
Opt.
HEADER, 3-PIN 1 ROW 0.079CC
HEADER, 2-PIN 2 ROW 0.079CC
HEADER, 2-PIN 4 ROW 0.079CC
SHUNT, 0.079" CENTER
HEADER, VERTICAL DUAL 2X7 0.079CC
RES., CHIP 4.99K 1% 0603
I.C., MICROPOWER SOT-23 LOW DROPOUT
I.C., PRECISION REFERENCE
I.C., SERIAL EEPROM, TSSOP-8
I.C., LTC2657BCUFD-L16, UFD-20
I.C., LTC2657BCUFD-H16, UFD-20
MANUFACTURER/PART NUMBER
AVX, 0603YC104MAT1A
AVX, 0603YC104MAT1A
TAIYO YUDEN, JMK212BJ475MG
TDK, C2012X5R0J106M
MILL-MAX, 2308-2
SAMTEC, TMM-103-02-L-S
SAMTEC, TMM-102-02-L-D
SAMTEC, TMM-104-02-L-D
SAMTEC, 2SN-BK-G
MOLEX, 87831-1420
VISHAY, CRCW06034K99FKEA
LINEAR TECH., LT1790ACS6
LINEAR TECH., LT1236ACS8-5
MICROCHIP, 24LC025-I/ST
LINEAR TECH., LTC2657BCUFD-L16#
LINEAR TECH., LTC2657BCUFD-H16#
