- Page 1 Assembly and Operating Instructions max. 180 kg ~ 90 Min. 58 kg L 122 | W 61 | H 154 CVEB2518.02.06 SKU: CVEB2518 Upright Bike UB10.5 Pro TF-UB10.5-2...
- Page 2 UB10.5...
- Page 3 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 4 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.
-
Page 5: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console display Button functions Powering on the equipment Standby mode MANUAL (Manual programmes) 3.5.1 Quick-Start programme 3.5.2 Target programmes PROGRAM (Profile programmes) USER (User defined programme) H.R.C. - Page 6 RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT UB10.5...
-
Page 7: General Information
GENERAL INFORMATION Technical Data LCD Display: Training duration in min. Speed in km/h Training distance in km Calories in kcal Heart rate (using the hand pulse sensors or a chest strap) Watts Brake system: Electro-magnetic induction brake Resistance levels: Fylwheel mass: 10 kg Wattage Adjustable range in the watt programme:... -
Page 8: Personal Safety
Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year. -
Page 9: Electrical Safety
Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠... -
Page 10: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries. -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... -
Page 12: Assembly
Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step 1: Mounting the front and rear stabiliser CAUTION... - Page 13 M8x1.25x70L M8x1.25x110L D15.4xD8.2x2T D16xD8.5x1.2T 9 16 9 16 Step-1...
- Page 14 Step 2: Mounting the saddle Mount the saddle to the seat post (13) and hand-tighten the nuts with the tool (see figs. 2-1 and 2-2). Pull the lock on the seat post (13) towards the saddle and insert the seat post (13) into the main frame (1) (see fig.
- Page 15 Step 3: Mounting the front post Slide the cover (75) on the front post (17) upwards (see fig. 3-1). Connect the two console cables (64 & 65) together (see fig. 3-2). ࣑ ATTENTION Make sure not to clamp the cables during the next step. Place the front post (17) on the main frame (1) and mount the front post (17) with four washers (16), four spring washers (9) and four screws (15).
- Page 16 Step 4: Mounting the console Connect the console cable (64) to the console cable (76) shown in figure 4-1. Pass the remaining console cables from the console (76) through the front post opening (17) (see fig. 4-2). Mount the console (76) on the front post (17) with four screws (39) (see fig. 4-3) and hand-tighten the screws.
- Page 17 Step 5: Mounting the handles and bottle holder Connect the cables from the console (76) to the cables for the speed buttons (37L & 37R). Mount the handlebar (36) to the front post (17) using two curved washers (8) and two screws (41) and hand-tighten the screws.
- Page 18 Step 6: Mounting the pedals and foot covers Turn the left pedal (51L) counterclockwise on the left crank (48L) on the main frame (1). Turn the right pedal (51R) clockwise on the right crank (48R) on the main frame (1). CAUTION ⚠...
- Page 19 Step 7: Alignment of the feet If the floor is uneven, you can stabilise the equipment by turning the adjustable screws under the main frame. Lift the equipment on the desired side and rotate the adjustable screws under the main frame. Rotate the screws clockwise in order to unscrew them, therefore raising the equipment.
-
Page 20: Operating Instructions
OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console display DISPLAY DESCRIPTION Display of the elapsed training time (0:00 - 99:59) TIME Set a target time with the rotary knob (0:00 - 99:00) in 1 min. -
Page 21: Button Functions
Button functions BUTTON DESCRIPTION Increasing the setting value or resistance level Rotary knob Decreasing the setting value or resistance level Setting confirmation BODY FAT Body fat test RECOVERY Heart rate test on your recovery condition Returns you to the previous training mode while making settings or RESET selecting an option. -
Page 22: Powering On The Equipment
Powering on the equipment The console starts automatically as soon as the exercise bike is plugged into the mains supply. Various components will light up. Choose a user profile (U1 - U4). Enter in your gender (SEX), age (AGE), height (HEIGHT) and weight (WEIGHT). You will proceed onto the main menu. -
Page 23: Manual (Manual Programmes)
MANUAL (Manual programmes) Under MANUAL you can choose between the Quick-Start programme and one of the target programmes. For target programmes, settings for time (TIME), distance (DISTANCE), caloires (CALORIES) or heart rate (PULSE) are possible. 3.5.1 Quick-Start programme In the main menu, select MANUAL and confirm your choice with a single push of the rotary knob. -
Page 24: Program (Profile Programmes)
Training with multiple target values In the main menu select MANUAL and confirm your choice with a single push of the rotary knob. Select your target value for time, calories, distance and/or heart rate with the rotary knob and confirm your choice with a single push of the rotary knob. ⚠... -
Page 26: User (User Defined Programme)
USER (User defined programme) There are 16 segments available in user defined programmes. In the main menu select USER and confirm your choice with a single push of the rotary knob. Select the resistance level of each segment and confirm each value with a single push of the rotary knob. -
Page 27: Heart Rate Controlled Programmes)
H.R.C. (Heart rate controlled programmes) WARNING ⚠ This crosstrainer is not medical equipment. The heart rate measurement of the crosstrainer can be unprecise. Different factors can influence the heart rate reading. The heart rate readings are only meant as a guide for training. There are three heart rate programmes available to choose from. -
Page 28: Watt (Watt Programme)
WATT (Watt programme) In the main menu select WATT and confirm your choice with a single push of the rotary knob. Using the rotary knob, select a Watt value and confirm your setting with a single push of the rotary knob. NOTICE The pre-set value is 120. -
Page 29: Body Fat (Body Fat Analysis)
3.11 BODY FAT (Body fat analysis) Choose your user profile (U1-U4). To start the body fat analysis, in the main menu press the BODY FAT button and hold on to the hand pulse sensors. NOTICE Should you not properly grip the hand pulse sensors, the display will show the error code E-1. NOTICE If you wish to prematurley end the body fat analysis and return to the previous program, press the BODY FAT button again. -
Page 30: Bluetooth And Fitness Apps
3.12 Bluetooth and fitness apps This console is equipped with a bluetooth interface. Please take note that your mobile device needs to be compatible with the bluetooth interface of the treadmill (bluetooth 4.0). To use training apps you will have to activate the bluetooth function on your mobile device (tablet or smart phone) and start the fitness app. -
Page 31: Storage And Transport
STORAGE AND TRANSPORT General Instructions ࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 5°C and 45°C. WARNING ⚠... -
Page 32: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 33: Maintenance And Inspection Calendar
Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Lubrication of moving parts Plastic covers... -
Page 34: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 35: Ordering Spare Parts
Standard/Norm: Maximum weight/max. Benutzergewicht: Class/Klasse: Date/Datum: Sport-Tiedje GmbH, Flensburger Str. 55, 24837 Schleswig MADE IN Serial nº.: Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / upright bike Model Name: UB10.5 Pro SKU: CVEB2518... -
Page 36: Parts List
Parts List Name Supplier Parts No. Specification Qty. Main frame 734G1-3-1000-BA0 Rear stabilizer 734S0-3-2112-BA0 Adjustable round wheel 76100-6-2174-B0 D50*M10*1.5 Front stabilizer 734S0-3-2100-BA0 Front stabilizer cover 734S0-6-2186-B0 600*190.2*79.4 Allen bolt 50308-5-0040-F3 M8*1.25*40L Bolt 50108-5-0070-F4 M8*1.25*70L Bolt 50108-5-0110-F5 M8*1.25*110L Curved waster 55108-3-2215-FA D22xD8.5x1.5T Spring washer 55108-2-1520-FA... - Page 37 Multi-groove belt 58004-6-1114-00 450 PJ8 Round magnet 174R4-6-2574-00 Upper cable for quick button(2) 734S0-6-2539-00 400L Upper cable for quick button(1) 734S0-6-2542-00 400L Upper cover for handpulse 747S0-6-2517-B0 184.5*20.8*50 Lower cover for handpulse 747S0-6-2518-B0 184.5*35.2*50 Membrane button(-) 734S0-6-2534-00 Membrane button (+) 734S0-6-2533-00 Handlebar 734S0-3-2400-J1...
- Page 38 Connecting cable(2) 747G0-6-3182-00 1000L "Battery connecting cable 818G0-6-2553-01 750L " Buffer 818G0-6-2594-B0 25*2T*80 Chargeable battery 818G0-6-2554-00 12V 2.6Ah Fixing board(1) 818G0-6-1085-BA0 77*48*2.0T Upper computer cable 747G0-6-2572-00 300L Middle computer cable 734G0-6-2587-00 1000L Lower computer cable 734G0-6-2573-00 1350L Tension cable 734S1-6-2603-00 D1.5x465L Controller 818G0-6-2597-00...
- Page 39 Tighten gasket 734S0-6-4086-B0 D38*11T Allen screw 54006-5-0045-F3 M6*1.0*45L Pull handle 734S0-6-2274-B0 152.5*53*32.2 End cap for adjustable handle 734S0-6-4085-B0 74*D37*3T Square neck bolt 50508-5-0050-D3 M8x1.25x50L Buffer 55308-4-0020-G9 D10.5*20L Block plate 734S0-6-4073-N0 31*31*6T Moving wheel 26100-6-1087-B0 D65*24 Round head cross screw 50805-2-0010-F0 M5x0.8x10L Inner hex fastening screw 54605-2-0012-D0...
-
Page 40: Exploded Drawing
Exploded Drawing UB10.5... -
Page 41: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 42 Warranty Service Within the warranty period, equipment which develops faults as a result of material or manufacturing defects, will be repaired or replaced at our discretion. Ownership of equipment or parts of equipment which have been replaced is transferred to us. The warranty period is not extended nor does a new warranty period begin following repair or replacement under the warranty.
-
Page 43: Contact
CONTACT TECHNIK TEKNIK OG SERVICE TECHNIQUE & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 189 530984 +49 4621 4210-945 +49 4621 42 10 933 �� +49 4621 4210-698 �� �� info@fitshop.dk info@fitshop.fr �� technik@sport-tiedje.de ��... - Page 44 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA The Sport-Tiedje Group is Europe’s largest http://www.powerhouse-fitness.co.uk/ specialist for home fitness equipment with www.powerhouse-fitness.co.uk/blog/ currently 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. https://www.facebook.com/powerhousefitness.co.uk Powerhouse Fitness is part of the Sport-Tiedje Group.
- Page 46 Upright Bike UB10.5 Pro...
