HOMCOM A90-308 Assembly Instruction Manual page 23

When not in use, you can save
space by folding the Sliding Rail
(No. 17).
Pull out the Pull Pin (No. 67) and
disassemble Knob (No.
(Figure A).
Fold the Sliding Rail (No. 17) to
a vertical angle. (Figure B)
SAFETY NOTE: the Seat (No.
69) will glide down when folding
the Sliding Rail (No. 17).
Reinsert Pull Pin (No. 67) into
the hole on the Main Frame (No.
49), then tighten Knob (No. 70)
to Sliding Rail (No. 17). (Figure
C)
Figure C
FOLDING THE ROWER
70)
-23-
Figure A
CAUTION!
Move with caution when you
vertically fold the Sliding
Rail (No. 17) as your head
may touch the Rear Support
(No. 14).
Figure B
CAUTION!
The Seat (NO. 69) will
glide down when folding
the Sliding Rail (No. 17)!
